SOLAR WIRING DIAGRAM SURVEY

The diagrams on this page are user-requested.  Help me to help you and let me know what solar setup you are working on by filling out this survey: https://www.explorist.life/solarsurvey

If you are looking for old wiring diagrams you can find those here:
https://www.explorist.life/solarwiringdiagrams-archive/

This is just one part of an overarching “How to Install a DIY Camper Van Electrical System” series.  If you’ve just stumbled on this article directly without seeing that, there are likely some things we’ve already covered.  If you want to check out that step by step guide, you can do that here: https://www.explorist.life/diy-campervan-solar

Watch the Video Below to Learn How to Best Use These Diagrams:

On the Images below, most of the components are clickable.  Play around with it and click on any of the images you want to know more information about.  Below the Image, there is a toggle bar you can click and see a shopping list for the ENTIRE project.

Here is a list of all of the different sizes of setups on this page. Click any of them to jump to that section specifically:

1200W Solar | 600Ah Batteries

600Ah Lithium Battery Bank – 4x300W Solar – 2kW Inverter/Charger – Li-BIM Alternator Charging
EXPLORIST.life / Battle Born Solar Bundle [Affiliate Link] 300W Solar Panels [Affiliate Link] 120A ANL Fuse [Affiliate Link] Roof Entry Gland [Affiliate Link] 100A ANL Fuse [Affiliate Link] 250A ANL Fuse [Affiliate Link] 250A ANL Fuse [Affiliate Link] 15A Solar Disconnect [Affiliate Link] Master Battery Disconnect Switch [Affiliate Link] Exterior Shore Power Outlet [Affiliate Link] 250A Terminal Fuse [Affiliate Link] 300A Terminal Fuse [Affiliate Link] 30 A Shore Power Cord [Affiliate Link] 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 4 AWG x 5/16 Wire Lug 6 AWG x 5/16 Wire Lug 4 AWG x 5/16 Wire Lug 4 AWG x 5/16 Wire Lug 6 AWG x 5/16 Wire Lug 4 AWG x 5/16 Wire Lug Tutorial: How to Wire the Li-BIM Battery Isolator Tutorial: How to Wire the AC Side of Your Electrical System Tutorial: How to Wire for Shore Power Tutorial: How to Wire a Battery Bank Tutorial: How to Wire a Busbar Tutorial: How To Wire DC Distribution Block & Accessories Tutorial: How to wire a power distribution panel

EXPLORIST.life / Battle Born Solar Bundle [Affiliate Link]

Battery, Inverter, Charge Controller, Battery Monitor Discount Bundle Coming June 1.

300W Solar Panels [Affiliate Link]

120A ANL Fuse [Affiliate Link]

Roof Entry Gland [Affiliate Link]

100A ANL Fuse [Affiliate Link]

250A ANL Fuse [Affiliate Link]

250A ANL Fuse [Affiliate Link]

15A Solar Disconnect [Affiliate Link]

Master Battery Disconnect Switch [Affiliate Link]

Exterior Shore Power Outlet [Affiliate Link]

250A Terminal Fuse [Affiliate Link]

300A Terminal Fuse [Affiliate Link]

30 A Shore Power Cord [Affiliate Link]

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

4 AWG x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

6 AWG x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

4 AWG x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

4 AWG x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

6 AWG x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

4 AWG x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

Tutorial: How to Wire the Li-BIM Battery Isolator

Tutorial: How to Wire the AC Side of Your Electrical System

Tutorial: How to Wire for Shore Power

Tutorial: How to Wire a Battery Bank

Tutorial: How to Wire a Busbar

Tutorial: How To Wire DC Distribution Block & Accessories

Tutorial: How to wire a power distribution panel

CLICK HERE TO EXPAND THE SHOPPING LIST FOR DIGRAM ABOVE
SYSTEM STATS:
Solar Array: 1200W (4x300W Panels)
Battery Bank: 600Ah (6x100Ah) Lithium – 12V
Inverter: 2000W Pure Sine Wave
Charging: Solar, Shore, Alternator
EXPLORIST.life Battery, Charge Controller, Inverter Bundle
Solar Charging System:
  • Qty: 1 – 300 Watt Solar Panel – 4 Pack
    • Put these in the sun
  • Qty: 1 – Solar Panel Mounting Feet
    • Help mount solar panels to the roof
  • Qty: 1 – MC4 Connectors
    • Connecting Solar Panels to Wires going to Charge Controller
  • Qty: 40 – 10 AWG Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Solar Panel to Charge Controller
  • Qty: 40 – 10 AWG Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Solar Panel to Charge Controller
  • Qty: 1 – Roof Entry Gland
    • Waterproof Box for Running Wires through Roof
  • Qty: 1 – 1″ Wire Grommet
    • Mounted in roof under Roof Entry Gland
  • Qty: 1 – 15 Amp Solar Disconnect Switch
    • Mounted on Din Rail Between Solar Panels & Solar Contoller
  • Qty: 1 – Din Rail
    • To mount the Solar Disconnect Switch
  • Qty: 1 – Victron Smartsolar MPPT 250 | 100 – Bundle
    • Included in Bundle at Top of List
    • Solar Charge Controller
  • Qty: 5 – 4 AWG Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Charge Controller to Busbar
  • Qty: 5 – 4 AWG Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between Busbar & Charge Controller Equipment Ground
  • Qty: 5 – 4 AWG Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Charge Controller to Busbar
  • Qty: 2 – 5/16″ x 4 AWG Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Positive & Negative Wires from Charge Controller to Busbar
  • Qty: 2 – 5/16″ x 4 AWG Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Connecting Busbar to Charge Controller Equipment Ground
  • Qty: 1 – 120 Amp ANL Fuse
    • Check Wire, Lug, and Fuse List at Bottom of List
    • On Positive Busbar Protecting Red Wire to Charge Controller
  • Qty: 1 – ANL Fuse Holder
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Mounted to Busbar under each ANL fuse
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

Battery Bank, Busbar, & Inverter
  • Qty: 1 – 2000W Victron MultiPlus Compact Inverter Charger 12V – Bundle
    • Included in Bundle at Top of List
    • This Converts Your 12v DC Power to 120v AC Power
  • Qty: 1 – 600Ah Battle Born Lithium Battery Bundle
    • Included in Bundle at Top of List
    • These Store Your Power
  • Qty: 8 – 2/0 Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between Batteries & From Batteries to Busbar
  • Qty: 8 – 2/0 Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between Batteries & From Batteries to Busbar
  • Qty: 24 – 5/16″ x 2/0 Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Wires to Batteries & to Busbar
  • Qty: 1 – 300 Amp Terminal Fuse
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attached to Battery Protecting Red Wire to Busbar
  • Qty: 5 – 2/0 Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between Busbar & Inverter
  • Qty: 5 – 2/0 Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between Busbar & Inverter
  • Qty: 5 – 2/0 Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between Busbar & Inverter Equipment Ground
  • Qty: 5 – 2/0 Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between Busbar & Chassis Ground
  • Qty: 2 – 5/16″ x 2/0 Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Positive Wire from Busbar to Inverter
  • Qty: 2 – 5/16″ x 2/0 Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Negative Wire from Busbar to Inverter
  • Qty: 2 – 5/16″ x 2/0 Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Black Wire from Negative Busbar to Inverter Equipment Ground
  • Qty: 2 – 5/16″ x 2/0 Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Black Wire from Negative Busbar to Vehicle Chassis Ground
  • Qty: 1 – 250 Amp ANL Fuse
    • Check Wire, Lug, and Fuse List at Bottom of List
    • On Positive Busbar Protecting Red Wire to Inverter
  • Qty: 1 – ANL Fuse Holder
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Mounted to Busbar under each ANL fuse
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

DC Busbar
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

AC Circuits & Shore Power
  • Qty: 1 – 30 Amp Shore Power Cord
    • Connecting 30A Flanged Power Inlet to Shore Power
  • Qty: 1 – 30 Amp Shore Power Extension Cord
    • If your Shore Power Cord is too Short
  • Qty: 1 – 30A to 15A Adapter
    • For plugging your 30A shore power cord into a 15/20 amp standard outlet.
  • Qty: 1 – 30A Flanged Power Inlet
    • Connected to Outside of Camper
  • Qty: 10 – 10 AWG 3 Conductor Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From 30A Flanged Power Inlet to Inverter
  • Qty: 5 – 6 AWG 3 Conductor Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Inverter to Power Distribution Panel
  • Qty: 1 – Power Distribution Panel
    • For Distributing Power & Housing Breakers/Fuses
  • Qty: 1 – 50A AC Breaker
    • Check Wire, Lug, and Fuse List at Bottom of List
    • For AC Branch Circuits
  • Qty: 1 – 20A HOMT Tandem AC Breaker
    • Check Wire, Lug, and Fuse List at Bottom of List
    • For Standard 120V Outlet Circuits
  • Qty: 1 – 20A / 30A HOMT Tandem AC Breaker
    • Check Wire, Lug, and Fuse List at Bottom of List
    • For Circuits that include large loads (hot water heater)
  • Qty: 50 – 12 AWG 3 Conductor Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • For AC Branch Circuits
  • Qty: 6 – 120V GFCI Outlet
    • For plugging 120V Appliances into
  • Qty: 6 – Single Gang Electrical Box
    • For 120V GFCI Outlet
  • Qty: 6 – GFCI Wall Plates
    • For 120V GFCI Outlet
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

12v Distribution
  • Qty: 1 – Power Distribution Panel
    • For Distributing Power & Housing Breakers/Fuses
  • Qty: 1 – 100 AMP ANL Fuse
    • Check Wire, Lug, and Fuse List at Bottom of List
    • On Positive Busbar Protecting Red Wire to the Power Distribution Panel
  • Qty: 1 – ANL Fuse Holder
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Mounted to Busbar under each ANL fuse
  • Qty: 2 – 5/16″ x 6 AWG Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Positive & Negatives Wires to the Busbar from the Power Distribution Panel
  • Qty: 5 – 6 AWG Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Positive Wire From Busbar to Power Distribution Panel
  • Qty: 5 – 6 AWG Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Negative Wire From Busbar to Power Distribution Panel
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

Alternator Charging
  • Qty: – LI-BIM 225 Isolator
    • Connects and Disconnects House and Starting Battery Banks
  • Qty: 5 – 2/0 Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between LI-BIM 225 Isolator & Start Battery
  • Qty: 20 – 2/0 Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between LI-BIM 225 Isolator & House Battery Bank
  • Qty: 1 – 250 Amp Terminal Fuse
    • Check Wire, Lug, and Fuse List at Bottom of List
    • On Starting Battery Protecting Red Wire to LI-BIM 225 Isolator
  • Qty: 1 – 250 Amp ANL Fuse
    • Check Wire, Lug, and Fuse List at Bottom of List
    • On Positive Busbar Protecting Red Wire to LI-BIM 225 Isolator
  • Qty: 1 – ANL Fuse Holder
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Mounted to Busbar under each ANL fuse
  • Qty: 4 – 5/16″ x 2/0 Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Positive Wire to Starting Battery, Isolator x2, & House Battery Bank
  • Qty: 5 – 16 AWG Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Isolator Ign to Ignition Positive
  • Qty: 1 – Add-a-Fuse Kit
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Used to piggyback power for Ignition+ Wire
  • Qty: 5 – 16 AWG Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Isolator Gnd to Chassis Ground
  • Qty: 10 – 16 AWG Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Isolator Sig to Momentary Switch & from Momentary Switch to Chassis Ground
  • Qty: 1 – Momentary Switch
    • Placed in-line on Isolator Sig Wire
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

Misc Tools & Accessories (As Needed/Optional)
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

Wires, Lugs, Breakers, and Fuses

Wires
Add Wires Individually to Verify Quantities

Lugs
Add Lugs Individually to Verify Quantities

Fuses & Breakers
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

1050W Solar | 600Ah Batteries

600Ah Lithium Battery Bank – 6x175W Solar – 2kW Inverter/Charger – Li-BIM Alternator Charging
EXPLORIST.life / Battle Born Solar Bundle [Affiliate Link] 175W Solar Panels [Affiliate Link] 150A ANL Fuse [Affiliate Link] Roof Entry Gland [Affiliate Link] 100A ANL Fuse [Affiliate Link] 250A ANL Fuse [Affiliate Link] 250A ANL Fuse [Affiliate Link] 15A Solar Disconnect [Affiliate Link] Master Battery Disconnect Switch [Affiliate Link] Exterior Shore Power Outlet [Affiliate Link] 250A Terminal Fuse [Affiliate Link] 300A Terminal Fuse [Affiliate Link] 30 A Shore Power Cord [Affiliate Link] 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2 AWG x 5/16 Wire Lug 6 AWG x 5/16 Wire Lug 2 AWG x 5/16 Wire Lug 2 AWG x 5/16 Wire Lug 6 AWG x 5/16 Wire Lug 2 AWG x 5/16 Wire Lug 2 AWG x 1/4 Wire Lug 2 AWG x 1/4 Wire Lug Tutorial: How to Wire the Li-BIM Battery Isolator Tutorial: How to Wire the AC Side of Your Electrical System Tutorial: How to Wire for Shore Power Tutorial: How to Wire a Battery Bank Tutorial: How to Wire a Busbar Tutorial: How To Wire DC Distribution Block & Accessories Tutorial: How To Install a Roof Entry Gland Tutorial: How to wire a Power Distribution Panel Power Distribution Panel - Amazon Affiliate Link

EXPLORIST.life / Battle Born Solar Bundle [Affiliate Link]

Battery, Inverter, Charge Controller, Battery Monitor Discount Bundle Coming June 1.

175W Solar Panels [Affiliate Link]

150A ANL Fuse [Affiliate Link]

Roof Entry Gland [Affiliate Link]

100A ANL Fuse [Affiliate Link]

250A ANL Fuse [Affiliate Link]

250A ANL Fuse [Affiliate Link]

15A Solar Disconnect [Affiliate Link]

Master Battery Disconnect Switch [Affiliate Link]

Exterior Shore Power Outlet [Affiliate Link]

250A Terminal Fuse [Affiliate Link]

300A Terminal Fuse [Affiliate Link]

30 A Shore Power Cord [Affiliate Link]

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2 AWG x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

6 AWG x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2 AWG x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2 AWG x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

6 AWG x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2 AWG x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2 AWG x 1/4 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2 AWG x 1/4 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

Tutorial: How to Wire the Li-BIM Battery Isolator

Tutorial: How to Wire the AC Side of Your Electrical System

Tutorial: How to Wire for Shore Power

Tutorial: How to Wire a Battery Bank

Tutorial: How to Wire a Busbar

Tutorial: How To Wire DC Distribution Block & Accessories

Tutorial: How To Install a Roof Entry Gland

Tutorial: How to wire a Power Distribution Panel

Power Distribution Panel - Amazon Affiliate Link

CLICK HERE TO EXPAND THE SHOPPING LIST FOR DIGRAM ABOVE
SYSTEM STATS:
Solar Array: 1050W (6x175W Panels)
Battery Bank: 600Ah (6x100Ah) Lithium – 12V
Inverter: 2000W Pure Sine Wave
Charging: Solar, Shore, Alternator
EXPLORIST.life Battery, Charge Controller, Inverter Bundle
Solar Charging System:
  • Qty: 6 – 175 Watt Solar Panel
    • Put these in the sun
  • Qty: 6 – Solar Panel Mounting Feet
    • Help mount solar panels to the roof
  • Qty: 1 – MC4 Connectors
    • Connecting Solar Panels to Wires going to Charge Controller
  • Qty: 40 – 10 AWG Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Solar Panel to Charge Controller
  • Qty: 40 – 10 AWG Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Solar Panel to Charge Controller
  • Qty: 1 – Roof Entry Gland
    • Waterproof Box for Running Wires through Roof
  • Qty: 1 – 1″ Wire Grommet
    • Mounted in roof under Roof Entry Gland
  • Qty: 1 – 15 Amp Solar Disconnect Switch
    • Mounted on Din Rail Between Solar Panels & Solar Contoller
  • Qty: 1 – Din Rail
    • To mount the Solar Disconnect Switch
  • Qty: 1 – Victron Smartsolar MPPT 250 | 100 – Bundle
    • Included in Bundle at Top of List
    • Solar Charge Controller
  • Qty: 5 – 4 AWG Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Charge Controller to Busbar
  • Qty: 5 – 4 AWG Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between Busbar & Charge Controller Equipment Ground
  • Qty: 5 – 4 AWG Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Charge Controller to Busbar
  • Qty: 2 – 5/16″ x 4 AWG Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Positive & Negative Wires from Charge Controller to Busbar
  • Qty: 2 – 5/16″ x 4 AWG Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Connecting Busbar to Charge Controller Equipment Ground
  • Qty: 1 – 150 Amp ANL Fuse
    • Check Wire, Lug, and Fuse List at Bottom of List
    • On Positive Busbar Protecting Red Wire to Charge Controller
  • Qty: 1 – ANL Fuse Holder
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Mounted to Busbar under each ANL fuse
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

Battery Bank, Busbar, & Inverter
  • Qty: 1 – 2000W Victron MultiPlus Compact Inverter Charger 12V – Bundle
    • Included in Bundle at Top of List
    • This Converts Your 12v DC Power to 120v AC Power
  • Qty: 1 – 600Ah Battle Born Lithium Battery Bundle
    • Included in Bundle at Top of List
    • These Store Your Power
  • Qty: 8 – 2/0 Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between Batteries & From Batteries to Busbar
  • Qty: 8 – 2/0 Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between Batteries & From Batteries to Busbar
  • Qty: 24 – 5/16″ x 2/0 Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Wires to Batteries & to Busbar
  • Qty: 1 – 300 Amp Terminal Fuse
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attached to Battery Protecting Red Wire to Busbar
  • Qty: 5 – 2/0 Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between Busbar & Inverter
  • Qty: 5 – 2/0 Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between Busbar & Inverter
  • Qty: 5 – 2/0 Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between Busbar & Inverter Equipment Ground
  • Qty: 5 – 2/0 Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between Busbar & Chassis Ground
  • Qty: 2 – 5/16″ x 2/0 Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Positive Wire from Busbar to Inverter
  • Qty: 2 – 5/16″ x 2/0 Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Negative Wire from Busbar to Inverter
  • Qty: 2 – 5/16″ x 2/0 Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Black Wire from Negative Busbar to Inverter Equipment Ground
  • Qty: 2 – 5/16″ x 2/0 Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Black Wire from Negative Busbar to Vehicle Chassis Ground
  • Qty: 1 – 250 Amp ANL Fuse
    • Check Wire, Lug, and Fuse List at Bottom of List
    • On Positive Busbar Protecting Red Wire to Inverter
  • Qty: 1 – ANL Fuse Holder
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Mounted to Busbar under each ANL fuse
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

DC Busbar
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

AC Circuits & Shore Power
  • Qty: 1 – 30 Amp Shore Power Cord
    • Connecting 30A Flanged Power Inlet to Shore Power
  • Qty: 1 – 30 Amp Shore Power Extension Cord
    • If your Shore Power Cord is too Short
  • Qty: 1 – 30A to 15A Adapter
    • For plugging your 30A shore power cord into a 15/20 amp standard outlet.
  • Qty: 1 – 30A Flanged Power Inlet
    • Connected to Outside of Camper
  • Qty: 10 – 10 AWG 3 Conductor Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From 30A Flanged Power Inlet to Inverter
  • Qty: 5 – 6 AWG 3 Conductor Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Inverter to Power Distribution Panel
  • Qty: 1 – Power Distribution Panel
    • For Distributing Power & Housing Breakers/Fuses
  • Qty: 1 – 50A AC Breaker
    • Check Wire, Lug, and Fuse List at Bottom of List
    • For AC Branch Circuits
  • Qty: 1 – 20A HOMT Tandem AC Breaker
    • Check Wire, Lug, and Fuse List at Bottom of List
    • For Standard 120V Outlet Circuits
  • Qty: 1 – 20A / 30A HOMT Tandem AC Breaker
    • Check Wire, Lug, and Fuse List at Bottom of List
    • For Circuits that include large loads (hot water heater)
  • Qty: 50 – 12 AWG 3 Conductor Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • For AC Branch Circuits
  • Qty: 6 – 120V GFCI Outlet
    • For plugging 120V Appliances into
  • Qty: 6 – Single Gang Electrical Box
    • For 120V GFCI Outlet
  • Qty: 6 – GFCI Wall Plates
    • For 120V GFCI Outlet
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

12v Distribution
  • Qty: 1 – Power Distribution Panel
    • For Distributing Power & Housing Breakers/Fuses
  • Qty: 1 – 100 AMP ANL Fuse
    • Check Wire, Lug, and Fuse List at Bottom of List
    • On Positive Busbar Protecting Red Wire to the Power Distribution Panel
  • Qty: 1 – ANL Fuse Holder
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Mounted to Busbar under each ANL fuse
  • Qty: 2 – 5/16″ x 6 AWG Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Positive & Negatives Wires to the Busbar from the Power Distribution Panel
  • Qty: 5 – 6 AWG Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Positive Wire From Busbar to Power Distribution Panel
  • Qty: 5 – 6 AWG Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Negative Wire From Busbar to Power Distribution Panel
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

Alternator Charging
  • Qty: – LI-BIM 225 Isolator
    • Connects and Disconnects House and Starting Battery Banks
  • Qty: 5 – 2/0 Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between LI-BIM 225 Isolator & Start Battery
  • Qty: 20 – 2/0 Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between LI-BIM 225 Isolator & House Battery Bank
  • Qty: 1 – 250 Amp Terminal Fuse
    • Check Wire, Lug, and Fuse List at Bottom of List
    • On Starting Battery Protecting Red Wire to LI-BIM 225 Isolator
  • Qty: 1 – 250 Amp ANL Fuse
    • Check Wire, Lug, and Fuse List at Bottom of List
    • On Positive Busbar Protecting Red Wire to LI-BIM 225 Isolator
  • Qty: 1 – ANL Fuse Holder
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Mounted to Busbar under each ANL fuse
  • Qty: 4 – 5/16″ x 2/0 Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Positive Wire to Starting Battery, Isolator x2, & House Battery Bank
  • Qty: 5 – 16 AWG Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Isolator Ign to Ignition Positive
  • Qty: 1 – Add-a-Fuse Kit
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Used to piggyback power for Ignition+ Wire
  • Qty: 5 – 16 AWG Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Isolator Gnd to Chassis Ground
  • Qty: 10 – 16 AWG Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Isolator Sig to Momentary Switch & from Momentary Switch to Chassis Ground
  • Qty: 1 – Momentary Switch
    • Placed in-line on Isolator Sig Wire
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

Misc Tools & Accessories (As Needed/Optional)
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

Wires, Lugs, Breakers, and Fuses

Wires
Add Wires Individually to Verify Quantities

Lugs
Add Lugs Individually to Verify Quantities

Fuses & Breakers
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

1050W Solar | 400Ah Batteries

400Ah Lithium Battery Bank – 6x175W Solar – 2kW Inverter/Charger – Li-BIM Alternator Charging
EXPLORIST.life / Battle Born Solar Bundle [Affiliate Link] 175W Solar Panels [Affiliate Link] 150A ANL Fuse [Affiliate Link] Roof Entry Gland [Affiliate Link] 100A ANL Fuse [Affiliate Link] 250A ANL Fuse [Affiliate Link] 250A ANL Fuse [Affiliate Link] 15A Solar Disconnect [Affiliate Link] Master Battery Disconnect Switch [Affiliate Link] GFCI Plugs [Affiliate Link] Exterior Shore Power Outlet [Affiliate Link] 250A Terminal Fuse [Affiliate Link] 300A Terminal Fuse [Affiliate Link] 30 A Shore Power Cord [Affiliate Link] 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2 AWG x 5/16 Wire Lug 6 AWG x 5/16 Wire Lug 2 AWG x 5/16 Wire Lug 2 AWG x 5/16 Wire Lug 6 AWG x 5/16 Wire Lug 2 AWG x 5/16 Wire Lug Tutorial: How to Wire the Li-BIM Battery Isolator Tutorial: How to Wire the AC Side of Your Electrical System Tutorial: How to Wire for Shore Power Tutorial: How to Wire a Battery Bank Tutorial: How to Wire a Busbar Tutorial: How To Wire DC Distribution Block & Accessories Tutorial: How To Install a Roof Entry Gland Tutorial: How to wire a power distribution panel Power Distribution Panel - Amazon Affiliate Link

EXPLORIST.life / Battle Born Solar Bundle [Affiliate Link]

Battery, Inverter, Charge Controller, Battery Monitor Discount Bundle Coming June 1.

175W Solar Panels [Affiliate Link]

150A ANL Fuse [Affiliate Link]

Roof Entry Gland [Affiliate Link]

100A ANL Fuse [Affiliate Link]

250A ANL Fuse [Affiliate Link]

250A ANL Fuse [Affiliate Link]

15A Solar Disconnect [Affiliate Link]

Master Battery Disconnect Switch [Affiliate Link]

GFCI Plugs [Affiliate Link]

Exterior Shore Power Outlet [Affiliate Link]

250A Terminal Fuse [Affiliate Link]

300A Terminal Fuse [Affiliate Link]

30 A Shore Power Cord [Affiliate Link]

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2 AWG x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

6 AWG x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2 AWG x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2 AWG x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

6 AWG x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2 AWG x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

Tutorial: How to Wire the Li-BIM Battery Isolator

Tutorial: How to Wire the AC Side of Your Electrical System

Tutorial: How to Wire for Shore Power

Tutorial: How to Wire a Battery Bank

Tutorial: How to Wire a Busbar

Tutorial: How To Wire DC Distribution Block & Accessories

Tutorial: How To Install a Roof Entry Gland

Tutorial: How to wire a power distribution panel

Power Distribution Panel - Amazon Affiliate Link

CLICK HERE TO EXPAND THE SHOPPING LIST FOR DIGRAM ABOVE
SYSTEM STATS:
Solar Array: 1050W (6x175W Panels)
Battery Bank: 400Ah (4x100Ah) Lithium – 12V
Inverter: 2000W Pure Sine Wave
Charging: Solar, Shore, Alternator
EXPLORIST.life Battery, Charge Controller, Inverter Bundle
Solar Charging System:
  • Qty: 6 – 175 Watt Solar Panel
    • Put these in the sun
  • Qty: 6 – Solar Panel Mounting Feet
    • Help mount solar panels to the roof
  • Qty: 1 – MC4 Connectors
    • Connecting Solar Panels to Wires going to Charge Controller
  • Qty: 40 – 10 AWG Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Solar Panel to Charge Controller
  • Qty: 40 – 10 AWG Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Solar Panel to Charge Controller
  • Qty: 1 – Roof Entry Gland
    • Waterproof Box for Running Wires through Roof
  • Qty: 1 – 1″ Wire Grommet
    • Mounted in roof under Roof Entry Gland
  • Qty: 1 – 15 Amp Solar Disconnect Switch
    • Mounted on Din Rail Between Solar Panels & Solar Contoller
  • Qty: 1 – Din Rail
    • To mount the Solar Disconnect Switch
  • Qty: 1 – Victron Smartsolar MPPT 250 | 100 – Bundle
    • Included in Bundle at Top of List
    • Solar Charge Controller
  • Qty: 5 – 4 AWG Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Charge Controller to Busbar
  • Qty: 5 – 4 AWG Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between Busbar & Charge Controller Equipment Ground
  • Qty: 5 – 4 AWG Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Charge Controller to Busbar
  • Qty: 2 – 5/16″ x 4 AWG Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Positive & Negative Wires from Charge Controller to Busbar
  • Qty: 2 – 5/16″ x 4 AWG Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Connecting Busbar to Charge Controller Equipment Ground
  • Qty: 1 – 150 Amp ANL Fuse
    • Check Wire, Lug, and Fuse List at Bottom of List
    • On Positive Busbar Protecting Red Wire to Charge Controller
  • Qty: 1 – ANL Fuse Holder
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Mounted to Busbar under each ANL fuse
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

Battery Bank, Busbar, & Inverter
  • Qty: 1 – 2000W Victron MultiPlus Compact Inverter Charger 12V – Bundle
    • Included in Bundle at Top of List
    • This Converts Your 12v DC Power to 120v AC Power
  • Qty: 1 – 200Ah Battle Born Lithium Battery Bundle
    • Included in Bundle at Top of List
    • These Store Your Power
  • Qty: 4 – 2/0 Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between Batteries & From Batteries to Busbar
  • Qty: 4 – 2/0 Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between Batteries & From Batteries to Busbar
  • Qty: 8 – 5/16″ x 2/0 Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Wires to Batteries & to Busbar
  • Qty: 1 – 300 Amp Terminal Fuse
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attached to Battery Protecting Red Wire to Busbar
  • Qty: 5 – 2/0 Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between Busbar & Inverter
  • Qty: 5 – 2/0 Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between Busbar & Inverter
  • Qty: 5 – 2/0 Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between Busbar & Inverter Equipment Ground
  • Qty: 5 – 2/0 Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between Busbar & Chassis Ground
  • Qty: 2 – 5/16″ x 2/0 Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Positive Wire from Busbar to Inverter
  • Qty: 2 – 5/16″ x 2/0 Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Negative Wire from Busbar to Inverter
  • Qty: 2 – 5/16″ x 2/0 Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Black Wire from Negative Busbar to Inverter Equipment Ground
  • Qty: 2 – 5/16″ x 2/0 Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Black Wire from Negative Busbar to Vehicle Chassis Ground
  • Qty: 1 – 250 Amp ANL Fuse
    • Check Wire, Lug, and Fuse List at Bottom of List
    • On Positive Busbar Protecting Red Wire to Inverter
  • Qty: 1 – ANL Fuse Holder
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Mounted to Busbar under each ANL fuse
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

DC Busbar
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

AC Circuits & Shore Power
  • Qty: 1 – 30 Amp Shore Power Cord
    • Connecting 30A Flanged Power Inlet to Shore Power
  • Qty: 1 – 30 Amp Shore Power Extension Cord
    • If your Shore Power Cord is too Short
  • Qty: 1 – 30A to 15A Adapter
    • For plugging your 30A shore power cord into a 15/20 amp standard outlet.
  • Qty: 1 – 30A Flanged Power Inlet
    • Connected to Outside of Camper
  • Qty: 10 – 10 AWG 3 Conductor Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From 30A Flanged Power Inlet to Inverter
  • Qty: 5 – 6 AWG 3 Conductor Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Inverter to Power Distribution Panel
  • Qty: 1 – Power Distribution Panel
    • For Distributing Power & Housing Breakers/Fuses
  • Qty: 1 – 50A AC Breaker
    • Check Wire, Lug, and Fuse List at Bottom of List
    • For AC Branch Circuits
  • Qty: 1 – 20A HOMT Tandem AC Breaker
    • Check Wire, Lug, and Fuse List at Bottom of List
    • For Standard 120V Outlet Circuits
  • Qty: 1 – 20A / 30A HOMT Tandem AC Breaker
    • Check Wire, Lug, and Fuse List at Bottom of List
    • For Circuits that include large loads (hot water heater)
  • Qty: 50 – 12 AWG 3 Conductor Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • For AC Branch Circuits
  • Qty: 6 – 120V GFCI Outlet
    • For plugging 120V Appliances into
  • Qty: 6 – Single Gang Electrical Box
    • For 120V GFCI Outlet
  • Qty: 6 – GFCI Wall Plates
    • For 120V GFCI Outlet
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

12v Distribution
  • Qty: 1 – Power Distribution Panel
    • For Distributing Power & Housing Breakers/Fuses
  • Qty: 1 – 100 AMP ANL Fuse
    • Check Wire, Lug, and Fuse List at Bottom of List
    • On Positive Busbar Protecting Red Wire to the Power Distribution Panel
  • Qty: 1 – ANL Fuse Holder
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Mounted to Busbar under each ANL fuse
  • Qty: 2 – 5/16″ x 6 AWG Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Positive & Negatives Wires to the Busbar from the Power Distribution Panel
  • Qty: 5 – 6 AWG Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Positive Wire From Busbar to Power Distribution Panel
  • Qty: 5 – 6 AWG Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Negative Wire From Busbar to Power Distribution Panel
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

Alternator Charging
  • Qty: – LI-BIM 225 Isolator
    • Connects and Disconnects House and Starting Battery Banks
  • Qty: 5 – 2/0 Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between LI-BIM 225 Isolator & Start Battery
  • Qty: 20 – 2/0 Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between LI-BIM 225 Isolator & House Battery Bank
  • Qty: 1 – 250 Amp Terminal Fuse
    • Check Wire, Lug, and Fuse List at Bottom of List
    • On Starting Battery Protecting Red Wire to LI-BIM 225 Isolator
  • Qty: 1 – 250 Amp ANL Fuse
    • Check Wire, Lug, and Fuse List at Bottom of List
    • On Positive Busbar Protecting Red Wire to LI-BIM 225 Isolator
  • Qty: 1 – ANL Fuse Holder
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Mounted to Busbar under each ANL fuse
  • Qty: 4 – 5/16″ x 2/0 Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Positive Wire to Starting Battery, Isolator x2, & House Battery Bank
  • Qty: 5 – 16 AWG Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Isolator Ign to Ignition Positive
  • Qty: 1 – Add-a-Fuse Kit
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Used to piggyback power for Ignition+ Wire
  • Qty: 5 – 16 AWG Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Isolator Gnd to Chassis Ground
  • Qty: 10 – 16 AWG Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Isolator Sig to Momentary Switch & from Momentary Switch to Chassis Ground
  • Qty: 1 – Momentary Switch
    • Placed in-line on Isolator Sig Wire
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

Misc Tools & Accessories (As Needed/Optional)
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

Wires, Lugs, Breakers, and Fuses

Wires
Add Wires Individually to Verify Quantities

Lugs
Add Lugs Individually to Verify Quantities

Fuses & Breakers
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

900W Solar | 400Ah Batteries

400Ah Lithium Battery Bank – 3x300W Solar – 2kW Inverter/Charger – Li-BIM Alternator Charging
EXPLORIST.life / Battle Born Solar Bundle [Affiliate Link] 300W Solar Panels [Affiliate Link] 120A ANL Fuse [Affiliate Link] Roof Entry Gland [Affiliate Link] 100A ANL Fuse [Affiliate Link] 250A ANL Fuse [Affiliate Link] 250A ANL Fuse [Affiliate Link] 15A Solar Disconnect [Affiliate Link] Master Battery Disconnect Switch [Affiliate Link] Exterior Shore Power Outlet [Affiliate Link] 250A Terminal Fuse [Affiliate Link] 300A Terminal Fuse [Affiliate Link] 30 A Shore Power Cord [Affiliate Link] 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 4 AWG x 5/16 Wire Lug 4 AWG x 5/16 Wire Lug 4 AWG x 5/16 Wire Lug 4 AWG x 5/16 Wire Lug Tutorial: How to Wire the Li-BIM Battery Isolator Tutorial: How to Wire the AC Side of Your Electrical System Tutorial: How to Wire for Shore Power Tutorial: How to Wire a Battery Bank Tutorial: How to Wire a Busbar Tutorial: How To Wire DC Distribution Block & Accessories Tutorial: How to wire a Power Distribution Panel

EXPLORIST.life / Battle Born Solar Bundle [Affiliate Link]

Battery, Inverter, Charge Controller, Battery Monitor Discount Bundle Coming June 1.

300W Solar Panels [Affiliate Link]

120A ANL Fuse [Affiliate Link]

Roof Entry Gland [Affiliate Link]

100A ANL Fuse [Affiliate Link]

250A ANL Fuse [Affiliate Link]

250A ANL Fuse [Affiliate Link]

15A Solar Disconnect [Affiliate Link]

Master Battery Disconnect Switch [Affiliate Link]

Exterior Shore Power Outlet [Affiliate Link]

250A Terminal Fuse [Affiliate Link]

300A Terminal Fuse [Affiliate Link]

30 A Shore Power Cord [Affiliate Link]

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

4 AWG x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

4 AWG x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

4 AWG x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

4 AWG x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

Tutorial: How to Wire the Li-BIM Battery Isolator

Tutorial: How to Wire the AC Side of Your Electrical System

Tutorial: How to Wire for Shore Power

Tutorial: How to Wire a Battery Bank

Tutorial: How to Wire a Busbar

Tutorial: How To Wire DC Distribution Block & Accessories

Tutorial: How to wire a Power Distribution Panel

CLICK HERE TO EXPAND THE SHOPPING LIST FOR DIGRAM ABOVE
SYSTEM STATS:
Solar Array: 900W (3x300W Panels)
Battery Bank: 600Ah (6x100Ah) Lithium – 12V
Inverter: 2000W Pure Sine Wave
Charging: Solar, Shore, Alternator
EXPLORIST.life Battery, Charge Controller, Inverter Bundle
Solar Charging System:
  • Qty: 1 – 300 Watt Solar Panel – 3 Pack
    • Put these in the sun
  • Qty: 1 – Solar Panel Mounting Feet
    • Help mount solar panels to the roof
  • Qty: 1 – MC4 Connectors
    • Connecting Solar Panels to Wires going to Charge Controller
  • Qty: 40 – 10 AWG Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Solar Panel to Charge Controller
  • Qty: 40 – 10 AWG Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Solar Panel to Charge Controller
  • Qty: 1 – Roof Entry Gland
    • Waterproof Box for Running Wires through Roof
  • Qty: 1 – 1″ Wire Grommet
    • Mounted in roof under Roof Entry Gland
  • Qty: 1 – 15 Amp Solar Disconnect Switch
    • Mounted on Din Rail Between Solar Panels & Solar Contoller
  • Qty: 1 – Din Rail
    • To mount the Solar Disconnect Switch
  • Qty: 1 – Victron Smartsolar MPPT 150 | 85 – Bundle
    • Included in Bundle at Top of List
    • Solar Charge Controller
  • Qty: 5 – 4 AWG Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Charge Controller to Busbar
  • Qty: 5 – 4 AWG Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between Busbar & Charge Controller Equipment Ground
  • Qty: 5 – 4 AWG Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Charge Controller to Busbar
  • Qty: 2 – 5/16″ x 4 AWG Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Positive & Negative Wires from Charge Controller to Busbar
  • Qty: 2 – 5/16″ x 4 AWG Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Connecting Busbar to Charge Controller Equipment Ground
  • Qty: 1 – 120 Amp ANL Fuse
    • Check Wire, Lug, and Fuse List at Bottom of List
    • On Positive Busbar Protecting Red Wire to Charge Controller
  • Qty: 1 – ANL Fuse Holder
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Mounted to Busbar under each ANL fuse
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

Battery Bank, Busbar, & Inverter
  • Qty: 1 – 2000W Victron MultiPlus Compact Inverter Charger 12V – Bundle
    • Included in Bundle at Top of List
    • This Converts Your 12v DC Power to 120v AC Power
  • Qty: 1 – 600Ah Battle Born Lithium Battery Bundle
    • Included in Bundle at Top of List
    • These Store Your Power
  • Qty: 8 – 2/0 Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between Batteries & From Batteries to Busbar
  • Qty: 8 – 2/0 Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between Batteries & From Batteries to Busbar
  • Qty: 24 – 5/16″ x 2/0 Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Wires to Batteries & to Busbar
  • Qty: 1 – 300 Amp Terminal Fuse
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attached to Battery Protecting Red Wire to Busbar
  • Qty: 5 – 2/0 Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between Busbar & Inverter
  • Qty: 5 – 2/0 Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between Busbar & Inverter
  • Qty: 5 – 2/0 Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between Busbar & Inverter Equipment Ground
  • Qty: 5 – 2/0 Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between Busbar & Chassis Ground
  • Qty: 2 – 5/16″ x 2/0 Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Positive Wire from Busbar to Inverter
  • Qty: 2 – 5/16″ x 2/0 Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Negative Wire from Busbar to Inverter
  • Qty: 2 – 5/16″ x 2/0 Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Black Wire from Negative Busbar to Inverter Equipment Ground
  • Qty: 2 – 5/16″ x 2/0 Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Black Wire from Negative Busbar to Vehicle Chassis Ground
  • Qty: 1 – 250 Amp ANL Fuse
    • Check Wire, Lug, and Fuse List at Bottom of List
    • On Positive Busbar Protecting Red Wire to Inverter
  • Qty: 1 – ANL Fuse Holder
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Mounted to Busbar under each ANL fuse
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

DC Busbar
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

AC Circuits & Shore Power
  • Qty: 1 – 30 Amp Shore Power Cord
    • Connecting 30A Flanged Power Inlet to Shore Power
  • Qty: 1 – 30 Amp Shore Power Extension Cord
    • If your Shore Power Cord is too Short
  • Qty: 1 – 30A to 15A Adapter
    • For plugging your 30A shore power cord into a 15/20 amp standard outlet.
  • Qty: 1 – 30A Flanged Power Inlet
    • Connected to Outside of Camper
  • Qty: 10 – 10 AWG 3 Conductor Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From 30A Flanged Power Inlet to Inverter
  • Qty: 5 – 6 AWG 3 Conductor Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Inverter to Power Distribution Panel
  • Qty: 1 – Power Distribution Panel
    • For Distributing Power & Housing Breakers/Fuses
  • Qty: 1 – 50A AC Breaker
    • Check Wire, Lug, and Fuse List at Bottom of List
    • For AC Branch Circuits
  • Qty: 1 – 20A HOMT Tandem AC Breaker
    • Check Wire, Lug, and Fuse List at Bottom of List
    • For Standard 120V Outlet Circuits
  • Qty: 1 – 20A / 30A HOMT Tandem AC Breaker
    • Check Wire, Lug, and Fuse List at Bottom of List
    • For Circuits that include large loads (hot water heater)
  • Qty: 50 – 12 AWG 3 Conductor Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • For AC Branch Circuits
  • Qty: 6 – 120V GFCI Outlet
    • For plugging 120V Appliances into
  • Qty: 6 – Single Gang Electrical Box
    • For 120V GFCI Outlet
  • Qty: 6 – GFCI Wall Plates
    • For 120V GFCI Outlet
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

12v Distribution
  • Qty: 1 – Power Distribution Panel
    • For Distributing Power & Housing Breakers/Fuses
  • Qty: 1 – 100 AMP ANL Fuse
    • Check Wire, Lug, and Fuse List at Bottom of List
    • On Positive Busbar Protecting Red Wire to the Power Distribution Panel
  • Qty: 1 – ANL Fuse Holder
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Mounted to Busbar under each ANL fuse
  • Qty: 2 – 5/16″ x 6 AWG Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Positive & Negatives Wires to the Busbar from the Power Distribution Panel
  • Qty: 5 – 6 AWG Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Positive Wire From Busbar to Power Distribution Panel
  • Qty: 5 – 6 AWG Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Negative Wire From Busbar to Power Distribution Panel
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

Alternator Charging
  • Qty: – LI-BIM 225 Isolator
    • Connects and Disconnects House and Starting Battery Banks
  • Qty: 5 – 2/0 Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between LI-BIM 225 Isolator & Start Battery
  • Qty: 20 – 2/0 Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between LI-BIM 225 Isolator & House Battery Bank
  • Qty: 1 – 250 Amp Terminal Fuse
    • Check Wire, Lug, and Fuse List at Bottom of List
    • On Starting Battery Protecting Red Wire to LI-BIM 225 Isolator
  • Qty: 1 – 250 Amp ANL Fuse
    • Check Wire, Lug, and Fuse List at Bottom of List
    • On Positive Busbar Protecting Red Wire to LI-BIM 225 Isolator
  • Qty: 1 – ANL Fuse Holder
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Mounted to Busbar under each ANL fuse
  • Qty: 4 – 5/16″ x 2/0 Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Positive Wire to Starting Battery, Isolator x2, & House Battery Bank
  • Qty: 5 – 16 AWG Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Isolator Ign to Ignition Positive
  • Qty: 1 – Add-a-Fuse Kit
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Used to piggyback power for Ignition+ Wire
  • Qty: 5 – 16 AWG Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Isolator Gnd to Chassis Ground
  • Qty: 10 – 16 AWG Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Isolator Sig to Momentary Switch & from Momentary Switch to Chassis Ground
  • Qty: 1 – Momentary Switch
    • Placed in-line on Isolator Sig Wire
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

Misc Tools & Accessories (As Needed/Optional)
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

Wires, Lugs, Breakers, and Fuses

Wires
Add Wires Individually to Verify Quantities

Lugs
Add Lugs Individually to Verify Quantities

Fuses & Breakers
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

875W Solar | 600Ah Batteries

600Ah Lithium Battery Bank – 5x175W Solar – 2kW Inverter/Charger – Li-BIM Alternator Charging
EXPLORIST.life / Battle Born Solar Bundle [Affiliate Link] 175W Solar Panels [Affiliate Link] 120A ANL Fuse [Affiliate Link] Roof Entry Gland [Affiliate Link] 100A ANL Fuse [Affiliate Link] 250A ANL Fuse [Affiliate Link] 250A ANL Fuse [Affiliate Link] 15A Solar Disconnect [Affiliate Link] Master Battery Disconnect Switch [Affiliate Link] Exterior Shore Power Outlet [Affiliate Link] 250A Terminal Fuse [Affiliate Link] 300A Terminal Fuse [Affiliate Link] 30 A Shore Power Cord [Affiliate Link] 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 4 AWG x 5/16 Wire Lug 6 AWG x 5/16 Wire Lug 4 AWG x 5/16 Wire Lug 4 AWG x 5/16 Wire Lug 6 AWG x 5/16 Wire Lug 4 AWG x 5/16 Wire Lug 2 AWG x 1/4 Wire Lug 2 AWG x 1/4 Wire Lug Tutorial: How to Wire the Li-BIM Battery Isolator Tutorial: How to Wire the AC Side of Your Electrical System Tutorial: How to Wire for Shore Power Tutorial: How to Wire a Battery Bank Tutorial: How to Wire a Busbar Tutorial: How To Wire DC Distribution Block & Accessories Tutorial: How to wire a power distribution panel

EXPLORIST.life / Battle Born Solar Bundle [Affiliate Link]

Battery, Inverter, Charge Controller, Battery Monitor Discount Bundle Coming June 1.

175W Solar Panels [Affiliate Link]

120A ANL Fuse [Affiliate Link]

Roof Entry Gland [Affiliate Link]

100A ANL Fuse [Affiliate Link]

250A ANL Fuse [Affiliate Link]

250A ANL Fuse [Affiliate Link]

15A Solar Disconnect [Affiliate Link]

Master Battery Disconnect Switch [Affiliate Link]

Exterior Shore Power Outlet [Affiliate Link]

250A Terminal Fuse [Affiliate Link]

300A Terminal Fuse [Affiliate Link]

30 A Shore Power Cord [Affiliate Link]

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

4 AWG x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

6 AWG x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

4 AWG x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

4 AWG x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

6 AWG x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

4 AWG x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2 AWG x 1/4 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2 AWG x 1/4 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

Tutorial: How to Wire the Li-BIM Battery Isolator

Tutorial: How to Wire the AC Side of Your Electrical System

Tutorial: How to Wire for Shore Power

Tutorial: How to Wire a Battery Bank

Tutorial: How to Wire a Busbar

Tutorial: How To Wire DC Distribution Block & Accessories

Tutorial: How to wire a power distribution panel

CLICK HERE TO EXPAND THE SHOPPING LIST FOR DIGRAM ABOVE
SYSTEM STATS:
Solar Array: 875W (5x175W Panels)
Battery Bank: 600Ah (6x100Ah) Lithium – 12V
Inverter: 2000W Pure Sine Wave
Charging: Solar, Shore, Alternator
EXPLORIST.life Battery, Charge Controller, Inverter Bundle
Solar Charging System:
  • Qty: 5 – 175 Watt Solar Panel
    • Put these in the sun
  • Qty: 5 – Solar Panel Mounting Feet
    • Help mount solar panels to the roof
  • Qty: 1 – MC4 Connectors
    • Connecting Solar Panels to Wires going to Charge Controller
  • Qty: 40 – 10 AWG Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Solar Panel to Charge Controller
  • Qty: 40 – 10 AWG Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Solar Panel to Charge Controller
  • Qty: 1 – Roof Entry Gland
    • Waterproof Box for Running Wires through Roof
  • Qty: 1 – 1″ Wire Grommet
    • Mounted in roof under Roof Entry Gland
  • Qty: 1 – 15 Amp Solar Disconnect Switch
    • Mounted on Din Rail Between Solar Panels & Solar Contoller
  • Qty: 1 – Din Rail
    • To mount the Solar Disconnect Switch
  • Qty: 1 – Victron Smartsolar MPPT 150 | 85 – Bundle
    • Included in Bundle at Top of List
    • Solar Charge Controller
  • Qty: 5 – 4 AWG Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Charge Controller to Busbar
  • Qty: 5 – 4 AWG Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between Busbar & Charge Controller Equipment Ground
  • Qty: 5 – 4 AWG Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Charge Controller to Busbar
  • Qty: 2 – 5/16″ x 4 AWG Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Positive & Negative Wires from Charge Controller to Busbar
  • Qty: 2 – 5/16″ x 4 AWG Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Connecting Busbar to Charge Controller Equipment Ground
  • Qty: 1 – 120 Amp ANL Fuse
    • Check Wire, Lug, and Fuse List at Bottom of List
    • On Positive Busbar Protecting Red Wire to Charge Controller
  • Qty: 1 – ANL Fuse Holder
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Mounted to Busbar under each ANL fuse
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

Battery Bank, Busbar, & Inverter
  • Qty: 1 – 2000W Victron MultiPlus Compact Inverter Charger 12V – Bundle
    • Included in Bundle at Top of List
    • This Converts Your 12v DC Power to 120v AC Power
  • Qty: 1 – 600Ah Battle Born Lithium Battery Bundle
    • Included in Bundle at Top of List
    • These Store Your Power
  • Qty: 8 – 2/0 Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between Batteries & From Batteries to Busbar
  • Qty: 8 – 2/0 Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between Batteries & From Batteries to Busbar
  • Qty: 24 – 5/16″ x 2/0 Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Wires to Batteries & to Busbar
  • Qty: 1 – 300 Amp Terminal Fuse
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attached to Battery Protecting Red Wire to Busbar
  • Qty: 5 – 2/0 Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between Busbar & Inverter
  • Qty: 5 – 2/0 Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between Busbar & Inverter
  • Qty: 5 – 2/0 Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between Busbar & Inverter Equipment Ground
  • Qty: 5 – 2/0 Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between Busbar & Chassis Ground
  • Qty: 2 – 5/16″ x 2/0 Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Positive Wire from Busbar to Inverter
  • Qty: 2 – 5/16″ x 2/0 Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Negative Wire from Busbar to Inverter
  • Qty: 2 – 5/16″ x 2/0 Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Black Wire from Negative Busbar to Inverter Equipment Ground
  • Qty: 2 – 5/16″ x 2/0 Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Black Wire from Negative Busbar to Vehicle Chassis Ground
  • Qty: 1 – 250 Amp ANL Fuse
    • Check Wire, Lug, and Fuse List at Bottom of List
    • On Positive Busbar Protecting Red Wire to Inverter
  • Qty: 1 – ANL Fuse Holder
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Mounted to Busbar under each ANL fuse
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

DC Busbar
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

AC Circuits & Shore Power
  • Qty: 1 – 30 Amp Shore Power Cord
    • Connecting 30A Flanged Power Inlet to Shore Power
  • Qty: 1 – 30 Amp Shore Power Extension Cord
    • If your Shore Power Cord is too Short
  • Qty: 1 – 30A to 15A Adapter
    • For plugging your 30A shore power cord into a 15/20 amp standard outlet.
  • Qty: 1 – 30A Flanged Power Inlet
    • Connected to Outside of Camper
  • Qty: 10 – 10 AWG 3 Conductor Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From 30A Flanged Power Inlet to Inverter
  • Qty: 5 – 6 AWG 3 Conductor Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Inverter to Power Distribution Panel
  • Qty: 1 – Power Distribution Panel
    • For Distributing Power & Housing Breakers/Fuses
  • Qty: 1 – 50A AC Breaker
    • Check Wire, Lug, and Fuse List at Bottom of List
    • For AC Branch Circuits
  • Qty: 1 – 20A HOMT Tandem AC Breaker
    • Check Wire, Lug, and Fuse List at Bottom of List
    • For Standard 120V Outlet Circuits
  • Qty: 1 – 20A / 30A HOMT Tandem AC Breaker
    • Check Wire, Lug, and Fuse List at Bottom of List
    • For Circuits that include large loads (hot water heater)
  • Qty: 50 – 12 AWG 3 Conductor Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • For AC Branch Circuits
  • Qty: 6 – 120V GFCI Outlet
    • For plugging 120V Appliances into
  • Qty: 6 – Single Gang Electrical Box
    • For 120V GFCI Outlet
  • Qty: 6 – GFCI Wall Plates
    • For 120V GFCI Outlet
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

12v Distribution
  • Qty: 1 – Power Distribution Panel
    • For Distributing Power & Housing Breakers/Fuses
  • Qty: 1 – 100 AMP ANL Fuse
    • Check Wire, Lug, and Fuse List at Bottom of List
    • On Positive Busbar Protecting Red Wire to the Power Distribution Panel
  • Qty: 1 – ANL Fuse Holder
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Mounted to Busbar under each ANL fuse
  • Qty: 2 – 5/16″ x 6 AWG Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Positive & Negatives Wires to the Busbar from the Power Distribution Panel
  • Qty: 5 – 6 AWG Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Positive Wire From Busbar to Power Distribution Panel
  • Qty: 5 – 6 AWG Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Negative Wire From Busbar to Power Distribution Panel
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

Alternator Charging
  • Qty: – LI-BIM 225 Isolator
    • Connects and Disconnects House and Starting Battery Banks
  • Qty: 5 – 2/0 Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between LI-BIM 225 Isolator & Start Battery
  • Qty: 20 – 2/0 Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between LI-BIM 225 Isolator & House Battery Bank
  • Qty: 1 – 250 Amp Terminal Fuse
    • Check Wire, Lug, and Fuse List at Bottom of List
    • On Starting Battery Protecting Red Wire to LI-BIM 225 Isolator
  • Qty: 1 – 250 Amp ANL Fuse
    • Check Wire, Lug, and Fuse List at Bottom of List
    • On Positive Busbar Protecting Red Wire to LI-BIM 225 Isolator
  • Qty: 1 – ANL Fuse Holder
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Mounted to Busbar under each ANL fuse
  • Qty: 4 – 5/16″ x 2/0 Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Positive Wire to Starting Battery, Isolator x2, & House Battery Bank
  • Qty: 5 – 16 AWG Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Isolator Ign to Ignition Positive
  • Qty: 1 – Add-a-Fuse Kit
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Used to piggyback power for Ignition+ Wire
  • Qty: 5 – 16 AWG Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Isolator Gnd to Chassis Ground
  • Qty: 10 – 16 AWG Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Isolator Sig to Momentary Switch & from Momentary Switch to Chassis Ground
  • Qty: 1 – Momentary Switch
    • Placed in-line on Isolator Sig Wire
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

Misc Tools & Accessories (As Needed/Optional)
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

Wires, Lugs, Breakers, and Fuses

Wires
Add Wires Individually to Verify Quantities

Lugs
Add Lugs Individually to Verify Quantities

Fuses & Breakers
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

600W Solar | 400Ah Batteries

400Ah Lithium Battery Bank – 2x300W Solar – 2kW Inverter/Charger – Li-BIM Alternator Charging
EXPLORIST.life / Battle Born Solar Bundle [Affiliate Link] 300W Solar Panels [Affiliate Link] 80A ANL Fuse [Affiliate Link] Roof Entry Gland [Affiliate Link] 100A ANL Fuse [Affiliate Link] 250A ANL Fuse [Affiliate Link] 250A ANL Fuse [Affiliate Link] 15A Solar Disconnect [Affiliate Link] Master Battery Disconnect Switch [Affiliate Link] Exterior Shore Power Outlet [Affiliate Link] 250A Terminal Fuse [Affiliate Link] 300A Terminal Fuse [Affiliate Link] 30 A Shore Power Cord [Affiliate Link] 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 6 AWG x 5/16 Wire Lug 6 AWG x 5/16 Wire Lug 6 AWG x 5/16 Wire Lug 6 AWG x 5/16 Wire Lug 6 AWG x 5/16 Wire Lug 6 AWG x 5/16 Wire Lug Tutorial: How to Wire the Li-BIM Battery Isolator Tutorial: How to Wire the AC Side of Your Electrical System Tutorial: How to Wire for Shore Power Tutorial: How to Wire a Battery Bank Tutorial: How to Wire a Busbar Tutorial: How To Wire DC Distribution Block & Accessories Tutorial: How To Install a Roof Entry Gland Tutorial: How to wire a power distribution panel Power Distribution Panel - Amazon Affiliate Link

EXPLORIST.life / Battle Born Solar Bundle [Affiliate Link]

Battery, Inverter, Charge Controller, Battery Monitor Discount Bundle Coming June 1.

300W Solar Panels [Affiliate Link]

80A ANL Fuse [Affiliate Link]

Roof Entry Gland [Affiliate Link]

100A ANL Fuse [Affiliate Link]

250A ANL Fuse [Affiliate Link]

250A ANL Fuse [Affiliate Link]

15A Solar Disconnect [Affiliate Link]

Master Battery Disconnect Switch [Affiliate Link]

Exterior Shore Power Outlet [Affiliate Link]

250A Terminal Fuse [Affiliate Link]

300A Terminal Fuse [Affiliate Link]

30 A Shore Power Cord [Affiliate Link]

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

6 AWG x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

6 AWG x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

6 AWG x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

6 AWG x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

6 AWG x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

6 AWG x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

Tutorial: How to Wire the Li-BIM Battery Isolator

Tutorial: How to Wire the AC Side of Your Electrical System

Tutorial: How to Wire for Shore Power

Tutorial: How to Wire a Battery Bank

Tutorial: How to Wire a Busbar

Tutorial: How To Wire DC Distribution Block & Accessories

Tutorial: How To Install a Roof Entry Gland

Tutorial: How to wire a power distribution panel

Power Distribution Panel - Amazon Affiliate Link

CLICK HERE TO EXPAND THE SHOPPING LIST FOR DIGRAM ABOVE
SYSTEM STATS:
Solar Array: 600W (2x300W Panels)
Battery Bank: 400Ah (4x100Ah) Lithium – 12V
Inverter: 2000W Pure Sine Wave
Charging: Solar, Shore, Alternator
EXPLORIST.life Battery, Charge Controller, Inverter Bundle
Solar Charging System:
  • Qty: 1 – 300 Watt Solar Panel – 2 Pack
    • Put these in the sun
  • Qty: 1 – Solar Panel Mounting Feet
    • Help mount solar panels to the roof
  • Qty: 1 – MC4 Connectors
    • Connecting Solar Panels to Wires going to Charge Controller
  • Qty: 40 – 10 AWG Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Solar Panel to Charge Controller
  • Qty: 40 – 10 AWG Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Solar Panel to Charge Controller
  • Qty: 1 – Roof Entry Gland
    • Waterproof Box for Running Wires through Roof
  • Qty: 1 – 1″ Wire Grommet
    • Mounted in roof under Roof Entry Gland
  • Qty: 1 – 15 Amp Solar Disconnect Switch
    • Mounted on Din Rail Between Solar Panels & Solar Contoller
  • Qty: 1 – Din Rail
    • To mount the Solar Disconnect Switch
  • Qty: 1 – Victron Smartsolar MPPT 150 | 60 – Bundle
    • Included in Bundle at Top of List
    • Solar Charge Controller
  • Qty: 5 – 6 AWG Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Charge Controller to Busbar
  • Qty: 5 – 6 AWG Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between Busbar & Charge Controller Equipment Ground
  • Qty: 5 – 6 AWG Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Charge Controller to Busbar
  • Qty: 2 – 5/16″ x 6 AWG Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Positive & Negative Wires from Charge Controller to Busbar
  • Qty: 2 – 5/16″ x 6 AWG Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Connecting Busbar to Charge Controller Equipment Ground
  • Qty: 1 – 80 Amp ANL Fuse
    • Check Wire, Lug, and Fuse List at Bottom of List
    • On Positive Busbar Protecting Red Wire to Charge Controller
  • Qty: 1 – ANL Fuse Holder
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Mounted to Busbar under each ANL fuse
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

Battery Bank, Busbar, & Inverter
  • Qty: 1 – 2000W Victron MultiPlus Compact Inverter Charger 12V – Bundle
    • Included in Bundle at Top of List
    • This Converts Your 12v DC Power to 120v AC Power
  • Qty: 1 – 400Ah Battle Born Lithium Battery Bundle
    • Included in Bundle at Top of List
    • These Store Your Power
  • Qty: 6 – 2/0 Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between Batteries & From Batteries to Busbar
  • Qty: 6 – 2/0 Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between Batteries & From Batteries to Busbar
  • Qty: 16 – 5/16″ x 2/0 Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Wires to Batteries & to Busbar
  • Qty: 1 – 300 Amp Terminal Fuse
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attached to Battery Protecting Red Wire to Busbar
  • Qty: 5 – 2/0 Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between Busbar & Inverter
  • Qty: 5 – 2/0 Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between Busbar & Inverter
  • Qty: 5 – 2/0 Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between Busbar & Inverter Equipment Ground
  • Qty: 5 – 2/0 Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between Busbar & Chassis Ground
  • Qty: 2 – 5/16″ x 2/0 Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Positive Wire from Busbar to Inverter
  • Qty: 2 – 5/16″ x 2/0 Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Negative Wire from Busbar to Inverter
  • Qty: 2 – 5/16″ x 2/0 Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Black Wire from Negative Busbar to Inverter Equipment Ground
  • Qty: 2 – 5/16″ x 2/0 Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Black Wire from Negative Busbar to Vehicle Chassis Ground
  • Qty: 1 – 250 Amp ANL Fuse
    • Check Wire, Lug, and Fuse List at Bottom of List
    • On Positive Busbar Protecting Red Wire to Inverter
  • Qty: 1 – ANL Fuse Holder
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Mounted to Busbar under each ANL fuse
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

DC Busbar
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

AC Circuits & Shore Power
  • Qty: 1 – 30 Amp Shore Power Cord
    • Connecting 30A Flanged Power Inlet to Shore Power
  • Qty: 1 – 30 Amp Shore Power Extension Cord
    • If your Shore Power Cord is too Short
  • Qty: 1 – 30A to 15A Adapter
    • For plugging your 30A shore power cord into a 15/20 amp standard outlet.
  • Qty: 1 – 30A Flanged Power Inlet
    • Connected to Outside of Camper
  • Qty: 10 – 10 AWG 3 Conductor Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From 30A Flanged Power Inlet to Inverter
  • Qty: 5 – 6 AWG 3 Conductor Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Inverter to Power Distribution Panel
  • Qty: 1 – Power Distribution Panel
    • For Distributing Power & Housing Breakers/Fuses
  • Qty: 1 – 50A AC Breaker
    • Check Wire, Lug, and Fuse List at Bottom of List
    • For AC Branch Circuits
  • Qty: 1 – 20A HOMT Tandem AC Breaker
    • Check Wire, Lug, and Fuse List at Bottom of List
    • For Standard 120V Outlet Circuits
  • Qty: 1 – 20A / 30A HOMT Tandem AC Breaker
    • Check Wire, Lug, and Fuse List at Bottom of List
    • For Circuits that include large loads (hot water heater)
  • Qty: 50 – 12 AWG 3 Conductor Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • For AC Branch Circuits
  • Qty: 6 – 120V GFCI Outlet
    • For plugging 120V Appliances into
  • Qty: 6 – Single Gang Electrical Box
    • For 120V GFCI Outlet
  • Qty: 6 – GFCI Wall Plates
    • For 120V GFCI Outlet
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

12v Distribution
  • Qty: 1 – Power Distribution Panel
    • For Distributing Power & Housing Breakers/Fuses
  • Qty: 1 – 100 AMP ANL Fuse
    • Check Wire, Lug, and Fuse List at Bottom of List
    • On Positive Busbar Protecting Red Wire to the Power Distribution Panel
  • Qty: 1 – ANL Fuse Holder
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Mounted to Busbar under each ANL fuse
  • Qty: 2 – 5/16″ x 6 AWG Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Positive & Negatives Wires to the Busbar from the Power Distribution Panel
  • Qty: 5 – 6 AWG Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Positive Wire From Busbar to Power Distribution Panel
  • Qty: 5 – 6 AWG Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Negative Wire From Busbar to Power Distribution Panel
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

Alternator Charging
  • Qty: – LI-BIM 225 Isolator
    • Connects and Disconnects House and Starting Battery Banks
  • Qty: 5 – 2/0 Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between LI-BIM 225 Isolator & Start Battery
  • Qty: 20 – 2/0 Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between LI-BIM 225 Isolator & House Battery Bank
  • Qty: 1 – 250 Amp Terminal Fuse
    • Check Wire, Lug, and Fuse List at Bottom of List
    • On Starting Battery Protecting Red Wire to LI-BIM 225 Isolator
  • Qty: 1 – 250 Amp ANL Fuse
    • Check Wire, Lug, and Fuse List at Bottom of List
    • On Positive Busbar Protecting Red Wire to LI-BIM 225 Isolator
  • Qty: 1 – ANL Fuse Holder
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Mounted to Busbar under each ANL fuse
  • Qty: 4 – 5/16″ x 2/0 Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Positive Wire to Starting Battery, Isolator x2, & House Battery Bank
  • Qty: 5 – 16 AWG Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Isolator Ign to Ignition Positive
  • Qty: 1 – Add-a-Fuse Kit
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Used to piggyback power for Ignition+ Wire
  • Qty: 5 – 16 AWG Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Isolator Gnd to Chassis Ground
  • Qty: 10 – 16 AWG Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Isolator Sig to Momentary Switch & from Momentary Switch to Chassis Ground
  • Qty: 1 – Momentary Switch
    • Placed in-line on Isolator Sig Wire
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

Misc Tools & Accessories (As Needed/Optional)
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

Wires, Lugs, Breakers, and Fuses

Wires
Add Wires Individually to Verify Quantities

Lugs
Add Lugs Individually to Verify Quantities

Fuses & Breakers
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

525W Solar | 600Ah Batteries

600Ah Lithium Battery Bank – 3x175W Solar – 2kW Inverter/Charger – Li-BIM Alternator Charging
EXPLORIST.life / Battle Born Solar Bundle [Affiliate Link] 175W Solar Panels [Affiliate Link] 80A ANL Fuse [Affiliate Link] Roof Entry Gland [Affiliate Link] 100A ANL Fuse [Affiliate Link] 250A ANL Fuse [Affiliate Link] 250A ANL Fuse [Affiliate Link] 15A Solar Disconnect [Affiliate Link] Master Battery Disconnect Switch [Affiliate Link] Exterior Shore Power Outlet [Affiliate Link] 250A Terminal Fuse [Affiliate Link] 300A Terminal Fuse [Affiliate Link] 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 6 AWG x 5/16 Wire Lug 6 AWG x 5/16 Wire Lug 6 AWG x 5/16 Wire Lug 6 AWG x 5/16 Wire Lug Tutorial: How to Wire the Li-BIM Battery Isolator Tutorial: How to Wire the AC Side of Your Electrical System Tutorial: How to Wire for Shore Power Tutorial: How to Wire a Battery Bank Tutorial: How to Wire a Busbar Tutorial: How To Wire DC Distribution Block & Accessories Tutorial: How To Install a Roof Entry Gland Power Distribution Panel - Amazon Affiliate Link Tutorial: How to wire a Power Distribution Panel

EXPLORIST.life / Battle Born Solar Bundle [Affiliate Link]

Battery, Inverter, Charge Controller, Battery Monitor Discount Bundle Coming June 1.

175W Solar Panels [Affiliate Link]

80A ANL Fuse [Affiliate Link]

Roof Entry Gland [Affiliate Link]

100A ANL Fuse [Affiliate Link]

250A ANL Fuse [Affiliate Link]

250A ANL Fuse [Affiliate Link]

15A Solar Disconnect [Affiliate Link]

Master Battery Disconnect Switch [Affiliate Link]

Exterior Shore Power Outlet [Affiliate Link]

250A Terminal Fuse [Affiliate Link]

300A Terminal Fuse [Affiliate Link]

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

6 AWG x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

6 AWG x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

6 AWG x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

6 AWG x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

Tutorial: How to Wire the Li-BIM Battery Isolator

Tutorial: How to Wire the AC Side of Your Electrical System

Tutorial: How to Wire for Shore Power

Tutorial: How to Wire a Battery Bank

Tutorial: How to Wire a Busbar

Tutorial: How To Wire DC Distribution Block & Accessories

Tutorial: How To Install a Roof Entry Gland

Power Distribution Panel - Amazon Affiliate Link

Tutorial: How to wire a Power Distribution Panel

CLICK HERE TO EXPAND THE SHOPPING LIST FOR DIGRAM ABOVE
SYSTEM STATS:
Solar Array: 525W (3x175W Panels)
Battery Bank: 600Ah (6x100Ah) Lithium – 12V
Inverter: 2000W Pure Sine Wave
Charging: Solar, Shore, Alternator
EXPLORIST.life Battery, Charge Controller, Inverter Bundle
Solar Charging System:
  • Qty: 3 – 175 Watt Solar Panel
    • Put these in the sun
  • Qty: 3 – Solar Panel Mounting Feet
    • Help mount solar panels to the roof
  • Qty: 1 – MC4 Connectors
    • Connecting Solar Panels to Wires going to Charge Controller
  • Qty: 40 – 10 AWG Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Solar Panel to Charge Controller
  • Qty: 40 – 10 AWG Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Solar Panel to Charge Controller
  • Qty: 1 – Roof Entry Gland
    • Waterproof Box for Running Wires through Roof
  • Qty: 1 – 1″ Wire Grommet
    • Mounted in roof under Roof Entry Gland
  • Qty: 1 – 15 Amp Solar Disconnect Switch
    • Mounted on Din Rail Between Solar Panels & Solar Contoller
  • Qty: 1 – Din Rail
    • To mount the Solar Disconnect Switch
  • Qty: 1 – Victron Smartsolar MPPT 150 | 60 – Bundle
    • Included in Bundle at Top of List
    • Solar Charge Controller
  • Qty: 5 – 6 AWG Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Charge Controller to Busbar
  • Qty: 5 – 6 AWG Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between Busbar & Charge Controller Equipment Ground
  • Qty: 5 – 6 AWG Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Charge Controller to Busbar
  • Qty: 2 – 5/16″ x 6 AWG Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Positive & Negative Wires from Charge Controller to Busbar
  • Qty: 2 – 5/16″ x 6 AWG Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Connecting Busbar to Charge Controller Equipment Ground
  • Qty: 1 – 80 Amp ANL Fuse
    • Check Wire, Lug, and Fuse List at Bottom of List
    • On Positive Busbar Protecting Red Wire to Charge Controller
  • Qty: 1 – ANL Fuse Holder
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Mounted to Busbar under each ANL fuse
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

Battery Bank, Busbar, & Inverter
  • Qty: 1 – 2000W Victron MultiPlus Compact Inverter Charger 12V – Bundle
    • Included in Bundle at Top of List
    • This Converts Your 12v DC Power to 120v AC Power
  • Qty: 1 – 600Ah Battle Born Lithium Battery Bundle
    • Included in Bundle at Top of List
    • These Store Your Power
  • Qty: 8 – 2/0 Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between Batteries & From Batteries to Busbar
  • Qty: 8 – 2/0 Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between Batteries & From Batteries to Busbar
  • Qty: 24 – 5/16″ x 2/0 Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Wires to Batteries & to Busbar
  • Qty: 1 – 300 Amp Terminal Fuse
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attached to Battery Protecting Red Wire to Busbar
  • Qty: 5 – 2/0 Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between Busbar & Inverter
  • Qty: 5 – 2/0 Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between Busbar & Inverter
  • Qty: 5 – 2/0 Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between Busbar & Inverter Equipment Ground
  • Qty: 5 – 2/0 Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between Busbar & Chassis Ground
  • Qty: 2 – 5/16″ x 2/0 Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Positive Wire from Busbar to Inverter
  • Qty: 2 – 5/16″ x 2/0 Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Negative Wire from Busbar to Inverter
  • Qty: 2 – 5/16″ x 2/0 Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Black Wire from Negative Busbar to Inverter Equipment Ground
  • Qty: 2 – 5/16″ x 2/0 Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Black Wire from Negative Busbar to Vehicle Chassis Ground
  • Qty: 1 – 250 Amp ANL Fuse
    • Check Wire, Lug, and Fuse List at Bottom of List
    • On Positive Busbar Protecting Red Wire to Inverter
  • Qty: 1 – ANL Fuse Holder
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Mounted to Busbar under each ANL fuse
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

DC Busbar
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

AC Circuits & Shore Power
  • Qty: 1 – 30 Amp Shore Power Cord
    • Connecting 30A Flanged Power Inlet to Shore Power
  • Qty: 1 – 30 Amp Shore Power Extension Cord
    • If your Shore Power Cord is too Short
  • Qty: 1 – 30A to 15A Adapter
    • For plugging your 30A shore power cord into a 15/20 amp standard outlet.
  • Qty: 1 – 30A Flanged Power Inlet
    • Connected to Outside of Camper
  • Qty: 10 – 10 AWG 3 Conductor Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From 30A Flanged Power Inlet to Inverter
  • Qty: 5 – 6 AWG 3 Conductor Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Inverter to Power Distribution Panel
  • Qty: 1 – Power Distribution Panel
    • For Distributing Power & Housing Breakers/Fuses
  • Qty: 1 – 50A AC Breaker
    • Check Wire, Lug, and Fuse List at Bottom of List
    • For AC Branch Circuits
  • Qty: 1 – 20A HOMT Tandem AC Breaker
    • Check Wire, Lug, and Fuse List at Bottom of List
    • For Standard 120V Outlet Circuits
  • Qty: 1 – 20A / 30A HOMT Tandem AC Breaker
    • Check Wire, Lug, and Fuse List at Bottom of List
    • For Circuits that include large loads (hot water heater)
  • Qty: 50 – 12 AWG 3 Conductor Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • For AC Branch Circuits
  • Qty: 6 – 120V GFCI Outlet
    • For plugging 120V Appliances into
  • Qty: 6 – Single Gang Electrical Box
    • For 120V GFCI Outlet
  • Qty: 6 – GFCI Wall Plates
    • For 120V GFCI Outlet
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

12v Distribution
  • Qty: 1 – Power Distribution Panel
    • For Distributing Power & Housing Breakers/Fuses
  • Qty: 1 – 100 AMP ANL Fuse
    • Check Wire, Lug, and Fuse List at Bottom of List
    • On Positive Busbar Protecting Red Wire to the Power Distribution Panel
  • Qty: 1 – ANL Fuse Holder
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Mounted to Busbar under each ANL fuse
  • Qty: 2 – 5/16″ x 6 AWG Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Positive & Negatives Wires to the Busbar from the Power Distribution Panel
  • Qty: 5 – 6 AWG Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Positive Wire From Busbar to Power Distribution Panel
  • Qty: 5 – 6 AWG Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Negative Wire From Busbar to Power Distribution Panel
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

Alternator Charging
  • Qty: – LI-BIM 225 Isolator
    • Connects and Disconnects House and Starting Battery Banks
  • Qty: 5 – 2/0 Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between LI-BIM 225 Isolator & Start Battery
  • Qty: 20 – 2/0 Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between LI-BIM 225 Isolator & House Battery Bank
  • Qty: 1 – 250 Amp Terminal Fuse
    • Check Wire, Lug, and Fuse List at Bottom of List
    • On Starting Battery Protecting Red Wire to LI-BIM 225 Isolator
  • Qty: 1 – 250 Amp ANL Fuse
    • Check Wire, Lug, and Fuse List at Bottom of List
    • On Positive Busbar Protecting Red Wire to LI-BIM 225 Isolator
  • Qty: 1 – ANL Fuse Holder
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Mounted to Busbar under each ANL fuse
  • Qty: 4 – 5/16″ x 2/0 Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Positive Wire to Starting Battery, Isolator x2, & House Battery Bank
  • Qty: 5 – 16 AWG Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Isolator Ign to Ignition Positive
  • Qty: 1 – Add-a-Fuse Kit
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Used to piggyback power for Ignition+ Wire
  • Qty: 5 – 16 AWG Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Isolator Gnd to Chassis Ground
  • Qty: 10 – 16 AWG Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Isolator Sig to Momentary Switch & from Momentary Switch to Chassis Ground
  • Qty: 1 – Momentary Switch
    • Placed in-line on Isolator Sig Wire
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

Misc Tools & Accessories (As Needed/Optional)
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

Wires, Lugs, Breakers, and Fuses

Wires
Add Wires Individually to Verify Quantities

Lugs
Add Lugs Individually to Verify Quantities

Fuses & Breakers
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

525W Solar | 500Ah Batteries

500Ah Lithium Battery Bank – 3x175W Solar – 2kW Inverter/Charger – Li-BIM Alternator Charging
EXPLORIST.life / Battle Born Solar Bundle [Affiliate Link] 175W Solar Panels [Affiliate Link] 80A ANL Fuse [Affiliate Link] Roof Entry Gland [Affiliate Link] 100A ANL Fuse [Affiliate Link] 250A ANL Fuse [Affiliate Link] 250A ANL Fuse [Affiliate Link] 15A Solar Disconnect [Affiliate Link] Master Battery Disconnect Switch [Affiliate Link] Exterior Shore Power Outlet [Affiliate Link] 250A Terminal Fuse [Affiliate Link] 300A Terminal Fuse [Affiliate Link] 30 A Shore Power Cord [Affiliate Link] DIN Rail Terminal Blocks [Affiliate Link] 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 6 AWG x 5/16 Wire Lug 6 AWG x 5/16 Wire Lug 6 AWG x 5/16 Wire Lug 6 AWG x 5/16 Wire Lug Tutorial: How to Wire the Li-BIM Battery Isolator Tutorial: How to Wire the AC Side of Your Electrical System Tutorial: How to Wire for Shore Power Tutorial: How to Wire a Battery Bank Tutorial: How to Wire a Busbar Tutorial: How To Wire DC Distribution Block & Accessories Tutorial: How To Install a Roof Entry Gland Tutorial: How to wire a power distribution panel Power Distribution Panel - Amazon Affiliate Link

EXPLORIST.life / Battle Born Solar Bundle [Affiliate Link]

Battery, Inverter, Charge Controller, Battery Monitor Discount Bundle Coming June 1.

175W Solar Panels [Affiliate Link]

80A ANL Fuse [Affiliate Link]

Roof Entry Gland [Affiliate Link]

100A ANL Fuse [Affiliate Link]

250A ANL Fuse [Affiliate Link]

250A ANL Fuse [Affiliate Link]

15A Solar Disconnect [Affiliate Link]

Master Battery Disconnect Switch [Affiliate Link]

Exterior Shore Power Outlet [Affiliate Link]

250A Terminal Fuse [Affiliate Link]

300A Terminal Fuse [Affiliate Link]

30 A Shore Power Cord [Affiliate Link]

DIN Rail Terminal Blocks [Affiliate Link]

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

6 AWG x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

6 AWG x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

6 AWG x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

6 AWG x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

Tutorial: How to Wire the Li-BIM Battery Isolator

Tutorial: How to Wire the AC Side of Your Electrical System

Tutorial: How to Wire for Shore Power

Tutorial: How to Wire a Battery Bank

Tutorial: How to Wire a Busbar

Tutorial: How To Wire DC Distribution Block & Accessories

Tutorial: How To Install a Roof Entry Gland

Tutorial: How to wire a power distribution panel

Power Distribution Panel - Amazon Affiliate Link

CLICK HERE TO EXPAND THE SHOPPING LIST FOR DIGRAM ABOVE
SYSTEM STATS:
Solar Array: 525W (3x175W Panels)
Battery Bank: 500Ah (5x100Ah) Lithium – 12V
Inverter: 2000W Pure Sine Wave
Charging: Solar, Shore, Alternator
EXPLORIST.life Battery, Charge Controller, Inverter Bundle
Solar Charging System:
  • Qty: 3 – 175 Watt Solar Panel
    • Put these in the sun
  • Qty: 3 – Solar Panel Mounting Feet
    • Help mount solar panels to the roof
  • Qty: 1 – MC4 Connectors
    • Connecting Solar Panels to Wires going to Charge Controller
  • Qty: 40 – 10 AWG Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Solar Panel to Charge Controller
  • Qty: 40 – 10 AWG Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Solar Panel to Charge Controller
  • Qty: 1 – Roof Entry Gland
    • Waterproof Box for Running Wires through Roof
  • Qty: 1 – 1″ Wire Grommet
    • Mounted in roof under Roof Entry Gland
  • Qty: 1 – 15 Amp Solar Disconnect Switch
    • Mounted on Din Rail Between Solar Panels & Solar Contoller
  • Qty: 1 – Din Rail
    • To mount the Solar Disconnect Switch
  • Qty: 1 – Victron Smartsolar MPPT 150 | 60 – Bundle
    • Included in Bundle at Top of List
    • Solar Charge Controller
  • Qty: 5 – 6 AWG Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Charge Controller to Busbar
  • Qty: 5 – 6 AWG Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between Busbar & Charge Controller Equipment Ground
  • Qty: 5 – 6 AWG Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Charge Controller to Busbar
  • Qty: 2 – 5/16″ x 6 AWG Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Positive & Negative Wires from Charge Controller to Busbar
  • Qty: 2 – 5/16″ x 6 AWG Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Connecting Busbar to Charge Controller Equipment Ground
  • Qty: 1 – 80 Amp ANL Fuse
    • Check Wire, Lug, and Fuse List at Bottom of List
    • On Positive Busbar Protecting Red Wire to Charge Controller
  • Qty: 1 – ANL Fuse Holder
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Mounted to Busbar under each ANL fuse
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

Battery Bank, Busbar, & Inverter
  • Qty: 1 – 2000W Victron MultiPlus Compact Inverter Charger 12V – Bundle
    • Included in Bundle at Top of List
    • This Converts Your 12v DC Power to 120v AC Power
  • Qty: 1 – 500Ah Battle Born Lithium Battery Bundle
    • Included in Bundle at Top of List
    • These Store Your Power
  • Qty: 7 – 2/0 Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between Batteries & From Batteries to Busbar
  • Qty: 7 – 2/0 Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between Batteries & From Batteries to Busbar
  • Qty: 20 – 5/16″ x 2/0 Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Wires to Batteries & to Busbar
  • Qty: 1 – 300 Amp Terminal Fuse
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attached to Battery Protecting Red Wire to Busbar
  • Qty: 5 – 2/0 Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between Busbar & Inverter
  • Qty: 5 – 2/0 Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between Busbar & Inverter
  • Qty: 5 – 2/0 Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between Busbar & Inverter Equipment Ground
  • Qty: 5 – 2/0 Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between Busbar & Chassis Ground
  • Qty: 2 – 5/16″ x 2/0 Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Positive Wire from Busbar to Inverter
  • Qty: 2 – 5/16″ x 2/0 Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Negative Wire from Busbar to Inverter
  • Qty: 2 – 5/16″ x 2/0 Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Black Wire from Negative Busbar to Inverter Equipment Ground
  • Qty: 2 – 5/16″ x 2/0 Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Black Wire from Negative Busbar to Vehicle Chassis Ground
  • Qty: 1 – 250 Amp ANL Fuse
    • Check Wire, Lug, and Fuse List at Bottom of List
    • On Positive Busbar Protecting Red Wire to Inverter
  • Qty: 1 – ANL Fuse Holder
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Mounted to Busbar under each ANL fuse
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

DC Busbar
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

AC Circuits & Shore Power
  • Qty: 1 – 30 Amp Shore Power Cord
    • Connecting 30A Flanged Power Inlet to Shore Power
  • Qty: 1 – 30 Amp Shore Power Extension Cord
    • If your Shore Power Cord is too Short
  • Qty: 1 – 30A to 15A Adapter
    • For plugging your 30A shore power cord into a 15/20 amp standard outlet.
  • Qty: 1 – 30A Flanged Power Inlet
    • Connected to Outside of Camper
  • Qty: 10 – 10 AWG 3 Conductor Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From 30A Flanged Power Inlet to Inverter
  • Qty: 5 – 6 AWG 3 Conductor Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Inverter to Power Distribution Panel
  • Qty: 1 – Power Distribution Panel
    • For Distributing Power & Housing Breakers/Fuses
  • Qty: 1 – 50A AC Breaker
    • Check Wire, Lug, and Fuse List at Bottom of List
    • For AC Branch Circuits
  • Qty: 1 – 20A HOMT Tandem AC Breaker
    • Check Wire, Lug, and Fuse List at Bottom of List
    • For Standard 120V Outlet Circuits
  • Qty: 1 – 20A / 30A HOMT Tandem AC Breaker
    • Check Wire, Lug, and Fuse List at Bottom of List
    • For Circuits that include large loads (hot water heater)
  • Qty: 50 – 12 AWG 3 Conductor Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • For AC Branch Circuits
  • Qty: 6 – 120V GFCI Outlet
    • For plugging 120V Appliances into
  • Qty: 6 – Single Gang Electrical Box
    • For 120V GFCI Outlet
  • Qty: 6 – GFCI Wall Plates
    • For 120V GFCI Outlet
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

12v Distribution
  • Qty: 1 – Power Distribution Panel
    • For Distributing Power & Housing Breakers/Fuses
  • Qty: 1 – 100 AMP ANL Fuse
    • Check Wire, Lug, and Fuse List at Bottom of List
    • On Positive Busbar Protecting Red Wire to the Power Distribution Panel
  • Qty: 1 – ANL Fuse Holder
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Mounted to Busbar under each ANL fuse
  • Qty: 2 – 5/16″ x 6 AWG Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Positive & Negatives Wires to the Busbar from the Power Distribution Panel
  • Qty: 5 – 6 AWG Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Positive Wire From Busbar to Power Distribution Panel
  • Qty: 5 – 6 AWG Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Negative Wire From Busbar to Power Distribution Panel
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

Alternator Charging
  • Qty: – LI-BIM 225 Isolator
    • Connects and Disconnects House and Starting Battery Banks
  • Qty: 5 – 2/0 Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between LI-BIM 225 Isolator & Start Battery
  • Qty: 20 – 2/0 Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between LI-BIM 225 Isolator & House Battery Bank
  • Qty: 1 – 250 Amp Terminal Fuse
    • Check Wire, Lug, and Fuse List at Bottom of List
    • On Starting Battery Protecting Red Wire to LI-BIM 225 Isolator
  • Qty: 1 – 250 Amp ANL Fuse
    • Check Wire, Lug, and Fuse List at Bottom of List
    • On Positive Busbar Protecting Red Wire to LI-BIM 225 Isolator
  • Qty: 1 – ANL Fuse Holder
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Mounted to Busbar under each ANL fuse
  • Qty: 4 – 5/16″ x 2/0 Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Positive Wire to Starting Battery, Isolator x2, & House Battery Bank
  • Qty: 5 – 16 AWG Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Isolator Ign to Ignition Positive
  • Qty: 1 – Add-a-Fuse Kit
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Used to piggyback power for Ignition+ Wire
  • Qty: 5 – 16 AWG Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Isolator Gnd to Chassis Ground
  • Qty: 10 – 16 AWG Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Isolator Sig to Momentary Switch & from Momentary Switch to Chassis Ground
  • Qty: 1 – Momentary Switch
    • Placed in-line on Isolator Sig Wire
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

Misc Tools & Accessories (As Needed/Optional)
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

Wires, Lugs, Breakers, and Fuses

Wires
Add Wires Individually to Verify Quantities

Lugs
Add Lugs Individually to Verify Quantities

Fuses & Breakers
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

525W Solar | 400Ah Batteries

400Ah Lithium Battery Bank – 3x175W Solar – 2kW Inverter/Charger – Li-BIM Alternator Charging
EXPLORIST.life / Battle Born Solar Bundle [Affiliate Link] 175W Solar Panels [Affiliate Link] 80A ANL Fuse [Affiliate Link] Roof Entry Gland [Affiliate Link] 100A ANL Fuse [Affiliate Link] 250A ANL Fuse [Affiliate Link] 250A ANL Fuse [Affiliate Link] 15A Solar Disconnect [Affiliate Link] Master Battery Disconnect Switch [Affiliate Link] Exterior Shore Power Outlet [Affiliate Link] 250A Terminal Fuse [Affiliate Link] 300A Terminal Fuse [Affiliate Link] 30 A Shore Power Cord [Affiliate Link] DIN Rail Terminal Blocks [Affiliate Link] 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 6 AWG x 5/16 Wire Lug 6 AWG x 5/16 Wire Lug 6 AWG x 5/16 Wire Lug 6 AWG x 5/16 Wire Lug 6 AWG x 5/16 Wire Lug 6 AWG x 5/16 Wire Lug Tutorial: How to Wire the Li-BIM Battery Isolator Tutorial: How to Wire the AC Side of Your Electrical System Tutorial: How to Wire for Shore Power Tutorial: How to Wire a Battery Bank Tutorial: How to Wire a Busbar Tutorial: How To Wire DC Distribution Block & Accessories Tutorial: How To Install a Roof Entry Gland Tutorial: How to wire a power distribution panel Power Distribution Panel - Amazon Affiliate Link

EXPLORIST.life / Battle Born Solar Bundle [Affiliate Link]

Battery, Inverter, Charge Controller, Battery Monitor Discount Bundle Coming June 1.

175W Solar Panels [Affiliate Link]

80A ANL Fuse [Affiliate Link]

Roof Entry Gland [Affiliate Link]

100A ANL Fuse [Affiliate Link]

250A ANL Fuse [Affiliate Link]

250A ANL Fuse [Affiliate Link]

15A Solar Disconnect [Affiliate Link]

Master Battery Disconnect Switch [Affiliate Link]

Exterior Shore Power Outlet [Affiliate Link]

250A Terminal Fuse [Affiliate Link]

300A Terminal Fuse [Affiliate Link]

30 A Shore Power Cord [Affiliate Link]

DIN Rail Terminal Blocks [Affiliate Link]

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

6 AWG x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

6 AWG x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

6 AWG x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

6 AWG x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

6 AWG x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

6 AWG x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

Tutorial: How to Wire the Li-BIM Battery Isolator

Tutorial: How to Wire the AC Side of Your Electrical System

Tutorial: How to Wire for Shore Power

Tutorial: How to Wire a Battery Bank

Tutorial: How to Wire a Busbar

Tutorial: How To Wire DC Distribution Block & Accessories

Tutorial: How To Install a Roof Entry Gland

Tutorial: How to wire a power distribution panel

Power Distribution Panel - Amazon Affiliate Link

CLICK HERE TO EXPAND THE SHOPPING LIST FOR DIGRAM ABOVE
SYSTEM STATS:
Solar Array: 525W (3x175W Panels)
Battery Bank: 400Ah (4x100Ah) Lithium – 12V
Inverter: 2000W Pure Sine Wave
Charging: Solar, Shore, Alternator
EXPLORIST.life Battery, Charge Controller, Inverter Bundle
Solar Charging System:
  • Qty: 3 – 175 Watt Solar Panel
    • Put these in the sun
  • Qty: 3 – Solar Panel Mounting Feet
    • Help mount solar panels to the roof
  • Qty: 1 – MC4 Connectors
    • Connecting Solar Panels to Wires going to Charge Controller
  • Qty: 40 – 10 AWG Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Solar Panel to Charge Controller
  • Qty: 40 – 10 AWG Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Solar Panel to Charge Controller
  • Qty: 1 – Roof Entry Gland
    • Waterproof Box for Running Wires through Roof
  • Qty: 1 – 1″ Wire Grommet
    • Mounted in roof under Roof Entry Gland
  • Qty: 1 – 15 Amp Solar Disconnect Switch
    • Mounted on Din Rail Between Solar Panels & Solar Contoller
  • Qty: 1 – Din Rail
    • To mount the Solar Disconnect Switch
  • Qty: 1 – Victron Smartsolar MPPT 150 | 60 – Bundle
    • Included in Bundle at Top of List
    • Solar Charge Controller
  • Qty: 5 – 6 AWG Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Charge Controller to Busbar
  • Qty: 5 – 6 AWG Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between Busbar & Charge Controller Equipment Ground
  • Qty: 5 – 6 AWG Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Charge Controller to Busbar
  • Qty: 2 – 5/16″ x 6 AWG Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Positive & Negative Wires from Charge Controller to Busbar
  • Qty: 2 – 5/16″ x 6 AWG Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Connecting Busbar to Charge Controller Equipment Ground
  • Qty: 1 – 80 Amp ANL Fuse
    • Check Wire, Lug, and Fuse List at Bottom of List
    • On Positive Busbar Protecting Red Wire to Charge Controller
  • Qty: 1 – ANL Fuse Holder
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Mounted to Busbar under each ANL fuse
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

Battery Bank, Busbar, & Inverter
  • Qty: 1 – 2000W Victron MultiPlus Compact Inverter Charger 12V – Bundle
    • Included in Bundle at Top of List
    • This Converts Your 12v DC Power to 120v AC Power
  • Qty: 1 – 400Ah Battle Born Lithium Battery Bundle
    • Included in Bundle at Top of List
    • These Store Your Power
  • Qty: 6 – 2/0 Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between Batteries & From Batteries to Busbar
  • Qty: 6 – 2/0 Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between Batteries & From Batteries to Busbar
  • Qty: 16 – 5/16″ x 2/0 Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Wires to Batteries & to Busbar
  • Qty: 1 – 300 Amp Terminal Fuse
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attached to Battery Protecting Red Wire to Busbar
  • Qty: 5 – 2/0 Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between Busbar & Inverter
  • Qty: 5 – 2/0 Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between Busbar & Inverter
  • Qty: 5 – 2/0 Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between Busbar & Inverter Equipment Ground
  • Qty: 5 – 2/0 Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between Busbar & Chassis Ground
  • Qty: 2 – 5/16″ x 2/0 Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Positive Wire from Busbar to Inverter
  • Qty: 2 – 5/16″ x 2/0 Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Negative Wire from Busbar to Inverter
  • Qty: 2 – 5/16″ x 2/0 Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Black Wire from Negative Busbar to Inverter Equipment Ground
  • Qty: 2 – 5/16″ x 2/0 Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Black Wire from Negative Busbar to Vehicle Chassis Ground
  • Qty: 1 – 250 Amp ANL Fuse
    • Check Wire, Lug, and Fuse List at Bottom of List
    • On Positive Busbar Protecting Red Wire to Inverter
  • Qty: 1 – ANL Fuse Holder
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Mounted to Busbar under each ANL fuse
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

DC Busbar
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

AC Circuits & Shore Power
  • Qty: 1 – 30 Amp Shore Power Cord
    • Connecting 30A Flanged Power Inlet to Shore Power
  • Qty: 1 – 30 Amp Shore Power Extension Cord
    • If your Shore Power Cord is too Short
  • Qty: 1 – 30A to 15A Adapter
    • For plugging your 30A shore power cord into a 15/20 amp standard outlet.
  • Qty: 1 – 30A Flanged Power Inlet
    • Connected to Outside of Camper
  • Qty: 10 – 10 AWG 3 Conductor Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From 30A Flanged Power Inlet to Inverter
  • Qty: 5 – 6 AWG 3 Conductor Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Inverter to Power Distribution Panel
  • Qty: 1 – Power Distribution Panel
    • For Distributing Power & Housing Breakers/Fuses
  • Qty: 1 – 50A AC Breaker
    • Check Wire, Lug, and Fuse List at Bottom of List
    • For AC Branch Circuits
  • Qty: 1 – 20A HOMT Tandem AC Breaker
    • Check Wire, Lug, and Fuse List at Bottom of List
    • For Standard 120V Outlet Circuits
  • Qty: 1 – 20A / 30A HOMT Tandem AC Breaker
    • Check Wire, Lug, and Fuse List at Bottom of List
    • For Circuits that include large loads (hot water heater)
  • Qty: 50 – 12 AWG 3 Conductor Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • For AC Branch Circuits
  • Qty: 6 – 120V GFCI Outlet
    • For plugging 120V Appliances into
  • Qty: 6 – Single Gang Electrical Box
    • For 120V GFCI Outlet
  • Qty: 6 – GFCI Wall Plates
    • For 120V GFCI Outlet
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

12v Distribution
  • Qty: 1 – Power Distribution Panel
    • For Distributing Power & Housing Breakers/Fuses
  • Qty: 1 – 100 AMP ANL Fuse
    • Check Wire, Lug, and Fuse List at Bottom of List
    • On Positive Busbar Protecting Red Wire to the Power Distribution Panel
  • Qty: 1 – ANL Fuse Holder
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Mounted to Busbar under each ANL fuse
  • Qty: 2 – 5/16″ x 6 AWG Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Positive & Negatives Wires to the Busbar from the Power Distribution Panel
  • Qty: 5 – 6 AWG Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Positive Wire From Busbar to Power Distribution Panel
  • Qty: 5 – 6 AWG Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Negative Wire From Busbar to Power Distribution Panel
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

Alternator Charging
  • Qty: – LI-BIM 225 Isolator
    • Connects and Disconnects House and Starting Battery Banks
  • Qty: 5 – 2/0 Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between LI-BIM 225 Isolator & Start Battery
  • Qty: 20 – 2/0 Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between LI-BIM 225 Isolator & House Battery Bank
  • Qty: 1 – 250 Amp Terminal Fuse
    • Check Wire, Lug, and Fuse List at Bottom of List
    • On Starting Battery Protecting Red Wire to LI-BIM 225 Isolator
  • Qty: 1 – 250 Amp ANL Fuse
    • Check Wire, Lug, and Fuse List at Bottom of List
    • On Positive Busbar Protecting Red Wire to LI-BIM 225 Isolator
  • Qty: 1 – ANL Fuse Holder
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Mounted to Busbar under each ANL fuse
  • Qty: 4 – 5/16″ x 2/0 Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Positive Wire to Starting Battery, Isolator x2, & House Battery Bank
  • Qty: 5 – 16 AWG Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Isolator Ign to Ignition Positive
  • Qty: 1 – Add-a-Fuse Kit
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Used to piggyback power for Ignition+ Wire
  • Qty: 5 – 16 AWG Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Isolator Gnd to Chassis Ground
  • Qty: 10 – 16 AWG Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Isolator Sig to Momentary Switch & from Momentary Switch to Chassis Ground
  • Qty: 1 – Momentary Switch
    • Placed in-line on Isolator Sig Wire
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

Misc Tools & Accessories (As Needed/Optional)
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

Wires, Lugs, Breakers, and Fuses

Wires
Add Wires Individually to Verify Quantities

Lugs
Add Lugs Individually to Verify Quantities

Fuses & Breakers
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

525W Solar | 300Ah Batteries

300Ah Lithium Battery Bank – 3x175W Solar – 2kW Inverter/Charger – Li-BIM Alternator Charging
EXPLORIST.life / Battle Born Solar Bundle [Affiliate Link] 175W Solar Panels [Affiliate Link] 80A ANL Fuse [Affiliate Link] Roof Entry Gland [Affiliate Link] 100A ANL Fuse [Affiliate Link] 250A ANL Fuse [Affiliate Link] 250A ANL Fuse [Affiliate Link] 15A Solar Disconnect [Affiliate Link] Master Battery Disconnect Switch [Affiliate Link] Exterior Shore Power Outlet [Affiliate Link] 250A Terminal Fuse [Affiliate Link] 300A Terminal Fuse [Affiliate Link] 30 A Shore Power Cord [Affiliate Link] DIN Rail Terminal Blocks [Affiliate Link] 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 6 AWG x 5/16 Wire Lug 6 AWG x 5/16 Wire Lug 6 AWG x 5/16 Wire Lug 6 AWG x 5/16 Wire Lug 6 AWG x 5/16 Wire Lug 6 AWG x 5/16 Wire Lug Tutorial: How to Wire the Li-BIM Battery Isolator Tutorial: How to Wire the AC Side of Your Electrical System Tutorial: How to Wire for Shore Power Tutorial: How to Wire a Battery Bank Tutorial: How to Wire a Busbar Tutorial: How To Wire DC Distribution Block & Accessories Tutorial: How To Install a Roof Entry Gland Power Distribution Panel - Amazon Affiliate Link Tutorial: How to wire a power distribution panel

EXPLORIST.life / Battle Born Solar Bundle [Affiliate Link]

Battery, Inverter, Charge Controller, Battery Monitor Discount Bundle Coming June 1.

175W Solar Panels [Affiliate Link]

80A ANL Fuse [Affiliate Link]

Roof Entry Gland [Affiliate Link]

100A ANL Fuse [Affiliate Link]

250A ANL Fuse [Affiliate Link]

250A ANL Fuse [Affiliate Link]

15A Solar Disconnect [Affiliate Link]

Master Battery Disconnect Switch [Affiliate Link]

Exterior Shore Power Outlet [Affiliate Link]

250A Terminal Fuse [Affiliate Link]

300A Terminal Fuse [Affiliate Link]

30 A Shore Power Cord [Affiliate Link]

DIN Rail Terminal Blocks [Affiliate Link]

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

6 AWG x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

6 AWG x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

6 AWG x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

6 AWG x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

6 AWG x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

6 AWG x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

Tutorial: How to Wire the Li-BIM Battery Isolator

Tutorial: How to Wire the AC Side of Your Electrical System

Tutorial: How to Wire for Shore Power

Tutorial: How to Wire a Battery Bank

Tutorial: How to Wire a Busbar

Tutorial: How To Wire DC Distribution Block & Accessories

Tutorial: How To Install a Roof Entry Gland

Power Distribution Panel - Amazon Affiliate Link

Tutorial: How to wire a power distribution panel

CLICK HERE TO EXPAND THE SHOPPING LIST FOR DIGRAM ABOVE
SYSTEM STATS:
Solar Array: 525W (3x175W Panels)
Battery Bank: 30000Ah (3x100Ah) Lithium – 12V
Inverter: 2000W Pure Sine Wave
Charging: Solar, Shore, Alternator
EXPLORIST.life Battery, Charge Controller, Inverter Bundle
Solar Charging System:
  • Qty: 3 – 175 Watt Solar Panel
    • Put these in the sun
  • Qty: 3 – Solar Panel Mounting Feet
    • Help mount solar panels to the roof
  • Qty: 1 – MC4 Connectors
    • Connecting Solar Panels to Wires going to Charge Controller
  • Qty: 40 – 10 AWG Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Solar Panel to Charge Controller
  • Qty: 40 – 10 AWG Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Solar Panel to Charge Controller
  • Qty: 1 – Roof Entry Gland
    • Waterproof Box for Running Wires through Roof
  • Qty: 1 – 1″ Wire Grommet
    • Mounted in roof under Roof Entry Gland
  • Qty: 1 – 15 Amp Solar Disconnect Switch
    • Mounted on Din Rail Between Solar Panels & Solar Contoller
  • Qty: 1 – Din Rail
    • To mount the Solar Disconnect Switch
  • Qty: 1 – Victron Smartsolar MPPT 150 | 60 – Bundle
    • Included in Bundle at Top of List
    • Solar Charge Controller
  • Qty: 5 – 6 AWG Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Charge Controller to Busbar
  • Qty: 5 – 6 AWG Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between Busbar & Charge Controller Equipment Ground
  • Qty: 5 – 6 AWG Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Charge Controller to Busbar
  • Qty: 2 – 5/16″ x 6 AWG Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Positive & Negative Wires from Charge Controller to Busbar
  • Qty: 2 – 5/16″ x 6 AWG Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Connecting Busbar to Charge Controller Equipment Ground
  • Qty: 1 – 80 Amp ANL Fuse
    • Check Wire, Lug, and Fuse List at Bottom of List
    • On Positive Busbar Protecting Red Wire to Charge Controller
  • Qty: 1 – ANL Fuse Holder
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Mounted to Busbar under each ANL fuse
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

Battery Bank, Busbar, & Inverter
  • Qty: 1 – 2000W Victron MultiPlus Compact Inverter Charger 12V – Bundle
    • Included in Bundle at Top of List
    • This Converts Your 12v DC Power to 120v AC Power
  • Qty: 1 – 300Ah Battle Born Lithium Battery Bundle
    • Included in Bundle at Top of List
    • These Store Your Power
  • Qty: 5 – 2/0 Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between Batteries & From Batteries to Busbar
  • Qty: 5 – 2/0 Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between Batteries & From Batteries to Busbar
  • Qty: 12 – 5/16″ x 2/0 Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Wires to Batteries & to Busbar
  • Qty: 1 – 300 Amp Terminal Fuse
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attached to Battery Protecting Red Wire to Busbar
  • Qty: 5 – 2/0 Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between Busbar & Inverter
  • Qty: 5 – 2/0 Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between Busbar & Inverter
  • Qty: 5 – 2/0 Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between Busbar & Inverter Equipment Ground
  • Qty: 5 – 2/0 Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between Busbar & Chassis Ground
  • Qty: 2 – 5/16″ x 2/0 Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Positive Wire from Busbar to Inverter
  • Qty: 2 – 5/16″ x 2/0 Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Negative Wire from Busbar to Inverter
  • Qty: 2 – 5/16″ x 2/0 Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Black Wire from Negative Busbar to Inverter Equipment Ground
  • Qty: 2 – 5/16″ x 2/0 Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Black Wire from Negative Busbar to Vehicle Chassis Ground
  • Qty: 1 – 250 Amp ANL Fuse
    • Check Wire, Lug, and Fuse List at Bottom of List
    • On Positive Busbar Protecting Red Wire to Inverter
  • Qty: 1 – ANL Fuse Holder
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Mounted to Busbar under each ANL fuse
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

DC Busbar
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

AC Circuits & Shore Power
  • Qty: 1 – 30 Amp Shore Power Cord
    • Connecting 30A Flanged Power Inlet to Shore Power
  • Qty: 1 – 30 Amp Shore Power Extension Cord
    • If your Shore Power Cord is too Short
  • Qty: 1 – 30A to 15A Adapter
    • For plugging your 30A shore power cord into a 15/20 amp standard outlet.
  • Qty: 1 – 30A Flanged Power Inlet
    • Connected to Outside of Camper
  • Qty: 10 – 10 AWG 3 Conductor Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From 30A Flanged Power Inlet to Inverter
  • Qty: 5 – 6 AWG 3 Conductor Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Inverter to Power Distribution Panel
  • Qty: 1 – Power Distribution Panel
    • For Distributing Power & Housing Breakers/Fuses
  • Qty: 1 – 50A AC Breaker
    • Check Wire, Lug, and Fuse List at Bottom of List
    • For AC Branch Circuits
  • Qty: 1 – 20A HOMT Tandem AC Breaker
    • Check Wire, Lug, and Fuse List at Bottom of List
    • For Standard 120V Outlet Circuits
  • Qty: 1 – 20A / 30A HOMT Tandem AC Breaker
    • Check Wire, Lug, and Fuse List at Bottom of List
    • For Circuits that include large loads (hot water heater)
  • Qty: 50 – 12 AWG 3 Conductor Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • For AC Branch Circuits
  • Qty: 6 – 120V GFCI Outlet
    • For plugging 120V Appliances into
  • Qty: 6 – Single Gang Electrical Box
    • For 120V GFCI Outlet
  • Qty: 6 – GFCI Wall Plates
    • For 120V GFCI Outlet
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

12v Distribution
  • Qty: 1 – Power Distribution Panel
    • For Distributing Power & Housing Breakers/Fuses
  • Qty: 1 – 100 AMP ANL Fuse
    • Check Wire, Lug, and Fuse List at Bottom of List
    • On Positive Busbar Protecting Red Wire to the Power Distribution Panel
  • Qty: 1 – ANL Fuse Holder
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Mounted to Busbar under each ANL fuse
  • Qty: 2 – 5/16″ x 6 AWG Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Positive & Negatives Wires to the Busbar from the Power Distribution Panel
  • Qty: 5 – 6 AWG Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Positive Wire From Busbar to Power Distribution Panel
  • Qty: 5 – 6 AWG Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Negative Wire From Busbar to Power Distribution Panel
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

Alternator Charging
  • Qty: – LI-BIM 225 Isolator
    • Connects and Disconnects House and Starting Battery Banks
  • Qty: 5 – 2/0 Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between LI-BIM 225 Isolator & Start Battery
  • Qty: 20 – 2/0 Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between LI-BIM 225 Isolator & House Battery Bank
  • Qty: 1 – 250 Amp Terminal Fuse
    • Check Wire, Lug, and Fuse List at Bottom of List
    • On Starting Battery Protecting Red Wire to LI-BIM 225 Isolator
  • Qty: 1 – 250 Amp ANL Fuse
    • Check Wire, Lug, and Fuse List at Bottom of List
    • On Positive Busbar Protecting Red Wire to LI-BIM 225 Isolator
  • Qty: 1 – ANL Fuse Holder
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Mounted to Busbar under each ANL fuse
  • Qty: 4 – 5/16″ x 2/0 Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Positive Wire to Starting Battery, Isolator x2, & House Battery Bank
  • Qty: 5 – 16 AWG Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Isolator Ign to Ignition Positive
  • Qty: 1 – Add-a-Fuse Kit
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Used to piggyback power for Ignition+ Wire
  • Qty: 5 – 16 AWG Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Isolator Gnd to Chassis Ground
  • Qty: 10 – 16 AWG Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Isolator Sig to Momentary Switch & from Momentary Switch to Chassis Ground
  • Qty: 1 – Momentary Switch
    • Placed in-line on Isolator Sig Wire
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

Misc Tools & Accessories (As Needed/Optional)
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

Wires, Lugs, Breakers, and Fuses

Wires
Add Wires Individually to Verify Quantities

Lugs
Add Lugs Individually to Verify Quantities

Fuses & Breakers
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

525W Solar | 200Ah Batteries

200Ah Lithium Battery Bank – 3x175W Solar – 2kW Inverter/Charger – Li-BIM Alternator Charging
EXPLORIST.life / Battle Born Solar Bundle [Affiliate Link] 175W Solar Panels [Affiliate Link] 80A ANL Fuse [Affiliate Link] Roof Entry Gland [Affiliate Link] 100A ANL Fuse [Affiliate Link] 250A ANL Fuse [Affiliate Link] 250A ANL Fuse [Affiliate Link] 15A Solar Disconnect [Affiliate Link] Master Battery Disconnect Switch [Affiliate Link] Exterior Shore Power Outlet [Affiliate Link] 250A Terminal Fuse [Affiliate Link] 300A Terminal Fuse [Affiliate Link] 30 A Shore Power Cord [Affiliate Link] 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 6 AWG x 5/16 Wire Lug 6 AWG x 5/16 Wire Lug 6 AWG x 5/16 Wire Lug 6 AWG x 5/16 Wire Lug 6 AWG x 5/16 Wire Lug 6 AWG x 5/16 Wire Lug 2 AWG x 1/4 Wire Lug 2 AWG x 1/4 Wire Lug Tutorial: How to Wire the Li-BIM Battery Isolator Tutorial: How to Wire the AC Side of Your Electrical System Tutorial: How to Wire for Shore Power Tutorial: How to Wire a Battery Bank Tutorial: How to Wire a Busbar Tutorial: How To Wire DC Distribution Block & Accessories Power Distribution Panel - Amazon Affiliate Link

EXPLORIST.life / Battle Born Solar Bundle [Affiliate Link]

Battery, Inverter, Charge Controller, Battery Monitor Discount Bundle Coming June 1.

175W Solar Panels [Affiliate Link]

80A ANL Fuse [Affiliate Link]

Roof Entry Gland [Affiliate Link]

100A ANL Fuse [Affiliate Link]

250A ANL Fuse [Affiliate Link]

250A ANL Fuse [Affiliate Link]

15A Solar Disconnect [Affiliate Link]

Master Battery Disconnect Switch [Affiliate Link]

Exterior Shore Power Outlet [Affiliate Link]

250A Terminal Fuse [Affiliate Link]

300A Terminal Fuse [Affiliate Link]

30 A Shore Power Cord [Affiliate Link]

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

6 AWG x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

6 AWG x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

6 AWG x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

6 AWG x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

6 AWG x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

6 AWG x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2 AWG x 1/4 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2 AWG x 1/4 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

Tutorial: How to Wire the Li-BIM Battery Isolator

Tutorial: How to Wire the AC Side of Your Electrical System

Tutorial: How to Wire for Shore Power

Tutorial: How to Wire a Battery Bank

Tutorial: How to Wire a Busbar

Tutorial: How To Wire DC Distribution Block & Accessories

Power Distribution Panel - Amazon Affiliate Link

CLICK HERE TO EXPAND THE SHOPPING LIST FOR DIGRAM ABOVE
SYSTEM STATS:
Solar Array: 525W (3x175W Panels)
Battery Bank: 200Ah (2x100Ah) Lithium – 12V
Inverter: 2000W Pure Sine Wave
Charging: Solar, Shore, Alternator
EXPLORIST.life Battery, Charge Controller, Inverter Bundle
Solar Charging System:
  • Qty: 3 – 175 Watt Solar Panel
    • Put these in the sun
  • Qty: 3 – Solar Panel Mounting Feet
    • Help mount solar panels to the roof
  • Qty: 1 – MC4 Connectors
    • Connecting Solar Panels to Wires going to Charge Controller
  • Qty: 40 – 10 AWG Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Solar Panel to Charge Controller
  • Qty: 40 – 10 AWG Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Solar Panel to Charge Controller
  • Qty: 1 – Roof Entry Gland
    • Waterproof Box for Running Wires through Roof
  • Qty: 1 – 1″ Wire Grommet
    • Mounted in roof under Roof Entry Gland
  • Qty: 1 – 15 Amp Solar Disconnect Switch
    • Mounted on Din Rail Between Solar Panels & Solar Contoller
  • Qty: 1 – Din Rail
    • To mount the Solar Disconnect Switch
  • Qty: 1 – Victron Smartsolar MPPT 150 | 60 – Bundle
    • Included in Bundle at Top of List
    • Solar Charge Controller
  • Qty: 5 – 6 AWG Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Charge Controller to Busbar
  • Qty: 5 – 6 AWG Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between Busbar & Charge Controller Equipment Ground
  • Qty: 5 – 6 AWG Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Charge Controller to Busbar
  • Qty: 2 – 5/16″ x 6 AWG Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Positive & Negative Wires from Charge Controller to Busbar
  • Qty: 2 – 5/16″ x 6 AWG Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Connecting Busbar to Charge Controller Equipment Ground
  • Qty: 1 – 80 Amp ANL Fuse
    • Check Wire, Lug, and Fuse List at Bottom of List
    • On Positive Busbar Protecting Red Wire to Charge Controller
  • Qty: 1 – ANL Fuse Holder
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Mounted to Busbar under each ANL fuse
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

Battery Bank, Busbar, & Inverter
  • Qty: 1 – 2000W Victron MultiPlus Compact Inverter Charger 12V – Bundle
    • Included in Bundle at Top of List
    • This Converts Your 12v DC Power to 120v AC Power
  • Qty: 1 – 200Ah Battle Born Lithium Battery Bundle
    • Included in Bundle at Top of List
    • These Store Your Power
  • Qty: 4 – 2/0 Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between Batteries & From Batteries to Busbar
  • Qty: 4 – 2/0 Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between Batteries & From Batteries to Busbar
  • Qty: 8 – 5/16″ x 2/0 Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Wires to Batteries & to Busbar
  • Qty: 1 – 300 Amp Terminal Fuse
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attached to Battery Protecting Red Wire to Busbar
  • Qty: 5 – 2/0 Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between Busbar & Inverter
  • Qty: 5 – 2/0 Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between Busbar & Inverter
  • Qty: 5 – 2/0 Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between Busbar & Inverter Equipment Ground
  • Qty: 5 – 2/0 Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between Busbar & Chassis Ground
  • Qty: 2 – 5/16″ x 2/0 Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Positive Wire from Busbar to Inverter
  • Qty: 2 – 5/16″ x 2/0 Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Negative Wire from Busbar to Inverter
  • Qty: 2 – 5/16″ x 2/0 Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Black Wire from Negative Busbar to Inverter Equipment Ground
  • Qty: 2 – 5/16″ x 2/0 Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Black Wire from Negative Busbar to Vehicle Chassis Ground
  • Qty: 1 – 250 Amp ANL Fuse
    • Check Wire, Lug, and Fuse List at Bottom of List
    • On Positive Busbar Protecting Red Wire to Inverter
  • Qty: 1 – ANL Fuse Holder
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Mounted to Busbar under each ANL fuse
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

DC Busbar
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

AC Circuits & Shore Power
  • Qty: 1 – 30 Amp Shore Power Cord
    • Connecting 30A Flanged Power Inlet to Shore Power
  • Qty: 1 – 30 Amp Shore Power Extension Cord
    • If your Shore Power Cord is too Short
  • Qty: 1 – 30A to 15A Adapter
    • For plugging your 30A shore power cord into a 15/20 amp standard outlet.
  • Qty: 1 – 30A Flanged Power Inlet
    • Connected to Outside of Camper
  • Qty: 10 – 10 AWG 3 Conductor Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From 30A Flanged Power Inlet to Inverter
  • Qty: 5 – 6 AWG 3 Conductor Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Inverter to Power Distribution Panel
  • Qty: 1 – Power Distribution Panel
    • For Distributing Power & Housing Breakers/Fuses
  • Qty: 1 – 50A AC Breaker
    • Check Wire, Lug, and Fuse List at Bottom of List
    • For AC Branch Circuits
  • Qty: 1 – 20A HOMT Tandem AC Breaker
    • Check Wire, Lug, and Fuse List at Bottom of List
    • For Standard 120V Outlet Circuits
  • Qty: 1 – 20A / 30A HOMT Tandem AC Breaker
    • Check Wire, Lug, and Fuse List at Bottom of List
    • For Circuits that include large loads (hot water heater)
  • Qty: 50 – 12 AWG 3 Conductor Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • For AC Branch Circuits
  • Qty: 6 – 120V GFCI Outlet
    • For plugging 120V Appliances into
  • Qty: 6 – Single Gang Electrical Box
    • For 120V GFCI Outlet
  • Qty: 6 – GFCI Wall Plates
    • For 120V GFCI Outlet
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

12v Distribution
  • Qty: 1 – Power Distribution Panel
    • For Distributing Power & Housing Breakers/Fuses
  • Qty: 1 – 100 AMP ANL Fuse
    • Check Wire, Lug, and Fuse List at Bottom of List
    • On Positive Busbar Protecting Red Wire to the Power Distribution Panel
  • Qty: 1 – ANL Fuse Holder
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Mounted to Busbar under each ANL fuse
  • Qty: 2 – 5/16″ x 6 AWG Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Positive & Negatives Wires to the Busbar from the Power Distribution Panel
  • Qty: 5 – 6 AWG Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Positive Wire From Busbar to Power Distribution Panel
  • Qty: 5 – 6 AWG Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Negative Wire From Busbar to Power Distribution Panel
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

Alternator Charging
  • Qty: – LI-BIM 225 Isolator
    • Connects and Disconnects House and Starting Battery Banks
  • Qty: 5 – 2/0 Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between LI-BIM 225 Isolator & Start Battery
  • Qty: 20 – 2/0 Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between LI-BIM 225 Isolator & House Battery Bank
  • Qty: 1 – 250 Amp Terminal Fuse
    • Check Wire, Lug, and Fuse List at Bottom of List
    • On Starting Battery Protecting Red Wire to LI-BIM 225 Isolator
  • Qty: 1 – 250 Amp ANL Fuse
    • Check Wire, Lug, and Fuse List at Bottom of List
    • On Positive Busbar Protecting Red Wire to LI-BIM 225 Isolator
  • Qty: 1 – ANL Fuse Holder
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Mounted to Busbar under each ANL fuse
  • Qty: 4 – 5/16″ x 2/0 Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Positive Wire to Starting Battery, Isolator x2, & House Battery Bank
  • Qty: 5 – 16 AWG Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Isolator Ign to Ignition Positive
  • Qty: 1 – Add-a-Fuse Kit
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Used to piggyback power for Ignition+ Wire
  • Qty: 5 – 16 AWG Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Isolator Gnd to Chassis Ground
  • Qty: 10 – 16 AWG Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Isolator Sig to Momentary Switch & from Momentary Switch to Chassis Ground
  • Qty: 1 – Momentary Switch
    • Placed in-line on Isolator Sig Wire
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

Misc Tools & Accessories (As Needed/Optional)
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

Wires, Lugs, Breakers, and Fuses

Wires
Add Wires Individually to Verify Quantities

Lugs
Add Lugs Individually to Verify Quantities

Fuses & Breakers
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

400W Solar | 400Ah Batteries

400Ah Lithium Battery Bank – 4x100W Solar – 2kW Inverter/Charger – Li-BIM Alternator Charging
EXPLORIST.life / Battle Born Solar Bundle [Affiliate Link] 100W Solar Panels [Affiliate Link] 50A ANL Fuse [Affiliate Link] Roof Entry Gland [Affiliate Link] 100A ANL Fuse [Affiliate Link] 250A ANL Fuse [Affiliate Link] 250A ANL Fuse [Affiliate Link] 15A Solar Disconnect [Affiliate Link] Master Battery Disconnect Switch [Affiliate Link] Exterior Shore Power Outlet [Affiliate Link] 250A Terminal Fuse [Affiliate Link] 300A Terminal Fuse [Affiliate Link] 30 A Shore Power Cord [Affiliate Link] 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 8 AWG x 5/16 Wire Lug 6 AWG x 5/16 Wire Lug 8 AWG x 5/16 Wire Lug 8 AWG x 5/16 Wire Lug 6 AWG x 5/16 Wire Lug 8 AWG x 5/16 Wire Lug Tutorial: How to Wire the Li-BIM Battery Isolator Tutorial: How to Wire the AC Side of Your Electrical System Tutorial: How to Wire for Shore Power Tutorial: How to Wire a Battery Bank Tutorial: How to Wire a Busbar Tutorial: How To Wire DC Distribution Block & Accessories Tutorial: How to wire a power distribution panel

EXPLORIST.life / Battle Born Solar Bundle [Affiliate Link]

Battery, Inverter, Charge Controller, Battery Monitor Discount Bundle Coming June 1.

100W Solar Panels [Affiliate Link]

50A ANL Fuse [Affiliate Link]

Roof Entry Gland [Affiliate Link]

100A ANL Fuse [Affiliate Link]

250A ANL Fuse [Affiliate Link]

250A ANL Fuse [Affiliate Link]

15A Solar Disconnect [Affiliate Link]

Master Battery Disconnect Switch [Affiliate Link]

Exterior Shore Power Outlet [Affiliate Link]

250A Terminal Fuse [Affiliate Link]

300A Terminal Fuse [Affiliate Link]

30 A Shore Power Cord [Affiliate Link]

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

8 AWG x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

6 AWG x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

8 AWG x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

8 AWG x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

6 AWG x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

8 AWG x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

Tutorial: How to Wire the Li-BIM Battery Isolator

Tutorial: How to Wire the AC Side of Your Electrical System

Tutorial: How to Wire for Shore Power

Tutorial: How to Wire a Battery Bank

Tutorial: How to Wire a Busbar

Tutorial: How To Wire DC Distribution Block & Accessories

Tutorial: How to wire a power distribution panel

CLICK HERE TO EXPAND THE SHOPPING LIST FOR DIGRAM ABOVE
SYSTEM STATS:
Solar Array: 400W (4x100W Panels)
Battery Bank: 400Ah (4x100Ah) Lithium – 12V
Inverter: 2000W Pure Sine Wave
Charging: Solar, Shore, Alternator
EXPLORIST.life Battery, Charge Controller, Inverter Bundle
Solar Charging System:
  • Qty: 4 – 100 Watt Solar Panel
    • Put these in the sun
  • Qty: 4 – Solar Panel Mounting Feet
    • Help mount solar panels to the roof
  • Qty: 1 – MC4 Connectors
    • Connecting Solar Panels to Wires going to Charge Controller
  • Qty: 40 – 10 AWG Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Solar Panel to Charge Controller
  • Qty: 40 – 10 AWG Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Solar Panel to Charge Controller
  • Qty: 1 – Roof Entry Gland
    • Waterproof Box for Running Wires through Roof
  • Qty: 1 – 1″ Wire Grommet
    • Mounted in roof under Roof Entry Gland
  • Qty: 1 – 15 Amp Solar Disconnect Switch
    • Mounted on Din Rail Between Solar Panels & Solar Contoller
  • Qty: 1 – Din Rail
    • To mount the Solar Disconnect Switch
  • Qty: 1 – Victron Smartsolar MPPT 150 | 35 – Bundle
    • Included in Bundle at Top of List
    • Solar Charge Controller
  • Qty: 5 – 8 AWG Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Charge Controller to Busbar
  • Qty: 5 – 8 AWG Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between Busbar & Charge Controller Equipment Ground
  • Qty: 5 – 8 AWG Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Charge Controller to Busbar
  • Qty: 2 – 5/16″ x 8 AWG Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Positive & Negative Wires from Charge Controller to Busbar
  • Qty: 2 – 5/16″ x 8 AWG Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Connecting Busbar to Charge Controller Equipment Ground
  • Qty: 1 – 50 Amp ANL Fuse
    • Check Wire, Lug, and Fuse List at Bottom of List
    • On Positive Busbar Protecting Red Wire to Charge Controller
  • Qty: 1 – ANL Fuse Holder
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Mounted to Busbar under each ANL fuse
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

Battery Bank, Busbar, & Inverter
  • Qty: 1 – 2000W Victron MultiPlus Compact Inverter Charger 12V – Bundle
    • Included in Bundle at Top of List
    • This Converts Your 12v DC Power to 120v AC Power
  • Qty: 1 – 400Ah Battle Born Lithium Battery Bundle
    • Included in Bundle at Top of List
    • These Store Your Power
  • Qty: 6 – 2/0 Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between Batteries & From Batteries to Busbar
  • Qty: 6 – 2/0 Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between Batteries & From Batteries to Busbar
  • Qty: 16 – 5/16″ x 2/0 Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Wires to Batteries & to Busbar
  • Qty: 1 – 300 Amp Terminal Fuse
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attached to Battery Protecting Red Wire to Busbar
  • Qty: 5 – 2/0 Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between Busbar & Inverter
  • Qty: 5 – 2/0 Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between Busbar & Inverter
  • Qty: 5 – 2/0 Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between Busbar & Inverter Equipment Ground
  • Qty: 5 – 2/0 Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between Busbar & Chassis Ground
  • Qty: 2 – 5/16″ x 2/0 Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Positive Wire from Busbar to Inverter
  • Qty: 2 – 5/16″ x 2/0 Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Negative Wire from Busbar to Inverter
  • Qty: 2 – 5/16″ x 2/0 Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Black Wire from Negative Busbar to Inverter Equipment Ground
  • Qty: 2 – 5/16″ x 2/0 Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Black Wire from Negative Busbar to Vehicle Chassis Ground
  • Qty: 1 – 250 Amp ANL Fuse
    • Check Wire, Lug, and Fuse List at Bottom of List
    • On Positive Busbar Protecting Red Wire to Inverter
  • Qty: 1 – ANL Fuse Holder
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Mounted to Busbar under each ANL fuse
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

DC Busbar
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

AC Circuits & Shore Power
  • Qty: 1 – 30 Amp Shore Power Cord
    • Connecting 30A Flanged Power Inlet to Shore Power
  • Qty: 1 – 30 Amp Shore Power Extension Cord
    • If your Shore Power Cord is too Short
  • Qty: 1 – 30A to 15A Adapter
    • For plugging your 30A shore power cord into a 15/20 amp standard outlet.
  • Qty: 1 – 30A Flanged Power Inlet
    • Connected to Outside of Camper
  • Qty: 10 – 10 AWG 3 Conductor Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From 30A Flanged Power Inlet to Inverter
  • Qty: 5 – 6 AWG 3 Conductor Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Inverter to Power Distribution Panel
  • Qty: 1 – Power Distribution Panel
    • For Distributing Power & Housing Breakers/Fuses
  • Qty: 1 – 50A AC Breaker
    • Check Wire, Lug, and Fuse List at Bottom of List
    • For AC Branch Circuits
  • Qty: 1 – 20A HOMT Tandem AC Breaker
    • Check Wire, Lug, and Fuse List at Bottom of List
    • For Standard 120V Outlet Circuits
  • Qty: 1 – 20A / 30A HOMT Tandem AC Breaker
    • Check Wire, Lug, and Fuse List at Bottom of List
    • For Circuits that include large loads (hot water heater)
  • Qty: 50 – 12 AWG 3 Conductor Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • For AC Branch Circuits
  • Qty: 6 – 120V GFCI Outlet
    • For plugging 120V Appliances into
  • Qty: 6 – Single Gang Electrical Box
    • For 120V GFCI Outlet
  • Qty: 6 – GFCI Wall Plates
    • For 120V GFCI Outlet
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

12v Distribution
  • Qty: 1 – Power Distribution Panel
    • For Distributing Power & Housing Breakers/Fuses
  • Qty: 1 – 100 AMP ANL Fuse
    • Check Wire, Lug, and Fuse List at Bottom of List
    • On Positive Busbar Protecting Red Wire to the Power Distribution Panel
  • Qty: 1 – ANL Fuse Holder
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Mounted to Busbar under each ANL fuse
  • Qty: 2 – 5/16″ x 6 AWG Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Positive & Negatives Wires to the Busbar from the Power Distribution Panel
  • Qty: 5 – 6 AWG Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Positive Wire From Busbar to Power Distribution Panel
  • Qty: 5 – 6 AWG Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Negative Wire From Busbar to Power Distribution Panel
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

Alternator Charging
  • Qty: – LI-BIM 225 Isolator
    • Connects and Disconnects House and Starting Battery Banks
  • Qty: 5 – 2/0 Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between LI-BIM 225 Isolator & Start Battery
  • Qty: 20 – 2/0 Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between LI-BIM 225 Isolator & House Battery Bank
  • Qty: 1 – 250 Amp Terminal Fuse
    • Check Wire, Lug, and Fuse List at Bottom of List
    • On Starting Battery Protecting Red Wire to LI-BIM 225 Isolator
  • Qty: 1 – 250 Amp ANL Fuse
    • Check Wire, Lug, and Fuse List at Bottom of List
    • On Positive Busbar Protecting Red Wire to LI-BIM 225 Isolator
  • Qty: 1 – ANL Fuse Holder
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Mounted to Busbar under each ANL fuse
  • Qty: 4 – 5/16″ x 2/0 Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Positive Wire to Starting Battery, Isolator x2, & House Battery Bank
  • Qty: 5 – 16 AWG Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Isolator Ign to Ignition Positive
  • Qty: 1 – Add-a-Fuse Kit
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Used to piggyback power for Ignition+ Wire
  • Qty: 5 – 16 AWG Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Isolator Gnd to Chassis Ground
  • Qty: 10 – 16 AWG Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Isolator Sig to Momentary Switch & from Momentary Switch to Chassis Ground
  • Qty: 1 – Momentary Switch
    • Placed in-line on Isolator Sig Wire
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

Misc Tools & Accessories (As Needed/Optional)
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

Wires, Lugs, Breakers, and Fuses

Wires
Add Wires Individually to Verify Quantities

Lugs
Add Lugs Individually to Verify Quantities

Fuses & Breakers
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

400W Solar | 300Ah Batteries

300Ah Lithium Battery Bank – 4x100W Solar – 2kW Inverter/Charger – Li-BIM Alternator Charging
EXPLORIST.life / Battle Born Solar Bundle [Affiliate Link] 100W Solar Panels [Affiliate Link] 50A ANL Fuse [Affiliate Link] Roof Entry Gland [Affiliate Link] 100A ANL Fuse [Affiliate Link] 250A ANL Fuse [Affiliate Link] 250A ANL Fuse [Affiliate Link] 15A Solar Disconnect [Affiliate Link] Master Battery Disconnect Switch [Affiliate Link] Exterior Shore Power Outlet [Affiliate Link] 250A Terminal Fuse [Affiliate Link] 300A Terminal Fuse [Affiliate Link] 30 A Shore Power Cord [Affiliate Link] 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 8 AWG x 5/16 Wire Lug 6 AWG x 5/16 Wire Lug 8 AWG x 5/16 Wire Lug 8 AWG x 5/16 Wire Lug 6 AWG x 5/16 Wire Lug 8 AWG x 5/16 Wire Lug Tutorial: How to Wire the Li-BIM Battery Isolator Tutorial: How to Wire the AC Side of Your Electrical System Tutorial: How to Wire for Shore Power Tutorial: How to Wire a Battery Bank Tutorial: How to Wire a Busbar Tutorial: How To Wire DC Distribution Block & Accessories Tutorial: How to wire a power distribution panel

EXPLORIST.life / Battle Born Solar Bundle [Affiliate Link]

Battery, Inverter, Charge Controller, Battery Monitor Discount Bundle Coming June 1.

100W Solar Panels [Affiliate Link]

50A ANL Fuse [Affiliate Link]

Roof Entry Gland [Affiliate Link]

100A ANL Fuse [Affiliate Link]

250A ANL Fuse [Affiliate Link]

250A ANL Fuse [Affiliate Link]

15A Solar Disconnect [Affiliate Link]

Master Battery Disconnect Switch [Affiliate Link]

Exterior Shore Power Outlet [Affiliate Link]

250A Terminal Fuse [Affiliate Link]

300A Terminal Fuse [Affiliate Link]

30 A Shore Power Cord [Affiliate Link]

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

8 AWG x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

6 AWG x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

8 AWG x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

8 AWG x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

6 AWG x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

8 AWG x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

Tutorial: How to Wire the Li-BIM Battery Isolator

Tutorial: How to Wire the AC Side of Your Electrical System

Tutorial: How to Wire for Shore Power

Tutorial: How to Wire a Battery Bank

Tutorial: How to Wire a Busbar

Tutorial: How To Wire DC Distribution Block & Accessories

Tutorial: How to wire a power distribution panel

CLICK HERE TO EXPAND THE SHOPPING LIST FOR DIGRAM ABOVE
SYSTEM STATS:
Solar Array: 400W (4x100W Panels)
Battery Bank: 300Ah (3x100Ah) Lithium – 12V
Inverter: 2000W Pure Sine Wave
Charging: Solar, Shore, Alternator
EXPLORIST.life Battery, Charge Controller, Inverter Bundle
Solar Charging System:
  • Qty: 4 – 100 Watt Solar Panel
    • Put these in the sun
  • Qty: 4 – Solar Panel Mounting Feet
    • Help mount solar panels to the roof
  • Qty: 1 – MC4 Connectors
    • Connecting Solar Panels to Wires going to Charge Controller
  • Qty: 40 – 10 AWG Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Solar Panel to Charge Controller
  • Qty: 40 – 10 AWG Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Solar Panel to Charge Controller
  • Qty: 1 – Roof Entry Gland
    • Waterproof Box for Running Wires through Roof
  • Qty: 1 – 1″ Wire Grommet
    • Mounted in roof under Roof Entry Gland
  • Qty: 1 – 15 Amp Solar Disconnect Switch
    • Mounted on Din Rail Between Solar Panels & Solar Contoller
  • Qty: 1 – Din Rail
    • To mount the Solar Disconnect Switch
  • Qty: 1 – Victron Smartsolar MPPT 150 | 35 – Bundle
    • Included in Bundle at Top of List
    • Solar Charge Controller
  • Qty: 5 – 8 AWG Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Charge Controller to Busbar
  • Qty: 5 – 8 AWG Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between Busbar & Charge Controller Equipment Ground
  • Qty: 5 – 8 AWG Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Charge Controller to Busbar
  • Qty: 2 – 5/16″ x 8 AWG Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Positive & Negative Wires from Charge Controller to Busbar
  • Qty: 2 – 5/16″ x 8 AWG Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Connecting Busbar to Charge Controller Equipment Ground
  • Qty: 1 – 50 Amp ANL Fuse
    • Check Wire, Lug, and Fuse List at Bottom of List
    • On Positive Busbar Protecting Red Wire to Charge Controller
  • Qty: 1 – ANL Fuse Holder
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Mounted to Busbar under each ANL fuse
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

Battery Bank, Busbar, & Inverter
  • Qty: 1 – 2000W Victron MultiPlus Compact Inverter Charger 12V – Bundle
    • Included in Bundle at Top of List
    • This Converts Your 12v DC Power to 120v AC Power
  • Qty: 1 – 300Ah Battle Born Lithium Battery Bundle
    • Included in Bundle at Top of List
    • These Store Your Power
  • Qty: 5 – 2/0 Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between Batteries & From Batteries to Busbar
  • Qty: 5 – 2/0 Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between Batteries & From Batteries to Busbar
  • Qty: 12 – 5/16″ x 2/0 Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Wires to Batteries & to Busbar
  • Qty: 1 – 300 Amp Terminal Fuse
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attached to Battery Protecting Red Wire to Busbar
  • Qty: 5 – 2/0 Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between Busbar & Inverter
  • Qty: 5 – 2/0 Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between Busbar & Inverter
  • Qty: 5 – 2/0 Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between Busbar & Inverter Equipment Ground
  • Qty: 5 – 2/0 Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between Busbar & Chassis Ground
  • Qty: 2 – 5/16″ x 2/0 Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Positive Wire from Busbar to Inverter
  • Qty: 2 – 5/16″ x 2/0 Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Negative Wire from Busbar to Inverter
  • Qty: 2 – 5/16″ x 2/0 Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Black Wire from Negative Busbar to Inverter Equipment Ground
  • Qty: 2 – 5/16″ x 2/0 Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Black Wire from Negative Busbar to Vehicle Chassis Ground
  • Qty: 1 – 250 Amp ANL Fuse
    • Check Wire, Lug, and Fuse List at Bottom of List
    • On Positive Busbar Protecting Red Wire to Inverter
  • Qty: 1 – ANL Fuse Holder
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Mounted to Busbar under each ANL fuse
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

DC Busbar
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

AC Circuits & Shore Power
  • Qty: 1 – 30 Amp Shore Power Cord
    • Connecting 30A Flanged Power Inlet to Shore Power
  • Qty: 1 – 30 Amp Shore Power Extension Cord
    • If your Shore Power Cord is too Short
  • Qty: 1 – 30A to 15A Adapter
    • For plugging your 30A shore power cord into a 15/20 amp standard outlet.
  • Qty: 1 – 30A Flanged Power Inlet
    • Connected to Outside of Camper
  • Qty: 10 – 10 AWG 3 Conductor Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From 30A Flanged Power Inlet to Inverter
  • Qty: 5 – 6 AWG 3 Conductor Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Inverter to Power Distribution Panel
  • Qty: 1 – Power Distribution Panel
    • For Distributing Power & Housing Breakers/Fuses
  • Qty: 1 – 50A AC Breaker
    • Check Wire, Lug, and Fuse List at Bottom of List
    • For AC Branch Circuits
  • Qty: 1 – 20A HOMT Tandem AC Breaker
    • Check Wire, Lug, and Fuse List at Bottom of List
    • For Standard 120V Outlet Circuits
  • Qty: 1 – 20A / 30A HOMT Tandem AC Breaker
    • Check Wire, Lug, and Fuse List at Bottom of List
    • For Circuits that include large loads (hot water heater)
  • Qty: 50 – 12 AWG 3 Conductor Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • For AC Branch Circuits
  • Qty: 6 – 120V GFCI Outlet
    • For plugging 120V Appliances into
  • Qty: 6 – Single Gang Electrical Box
    • For 120V GFCI Outlet
  • Qty: 6 – GFCI Wall Plates
    • For 120V GFCI Outlet
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

12v Distribution
  • Qty: 1 – Power Distribution Panel
    • For Distributing Power & Housing Breakers/Fuses
  • Qty: 1 – 100 AMP ANL Fuse
    • Check Wire, Lug, and Fuse List at Bottom of List
    • On Positive Busbar Protecting Red Wire to the Power Distribution Panel
  • Qty: 1 – ANL Fuse Holder
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Mounted to Busbar under each ANL fuse
  • Qty: 2 – 5/16″ x 6 AWG Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Positive & Negatives Wires to the Busbar from the Power Distribution Panel
  • Qty: 5 – 6 AWG Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Positive Wire From Busbar to Power Distribution Panel
  • Qty: 5 – 6 AWG Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Negative Wire From Busbar to Power Distribution Panel
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

Alternator Charging
  • Qty: – LI-BIM 225 Isolator
    • Connects and Disconnects House and Starting Battery Banks
  • Qty: 5 – 2/0 Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between LI-BIM 225 Isolator & Start Battery
  • Qty: 20 – 2/0 Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between LI-BIM 225 Isolator & House Battery Bank
  • Qty: 1 – 250 Amp Terminal Fuse
    • Check Wire, Lug, and Fuse List at Bottom of List
    • On Starting Battery Protecting Red Wire to LI-BIM 225 Isolator
  • Qty: 1 – 250 Amp ANL Fuse
    • Check Wire, Lug, and Fuse List at Bottom of List
    • On Positive Busbar Protecting Red Wire to LI-BIM 225 Isolator
  • Qty: 1 – ANL Fuse Holder
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Mounted to Busbar under each ANL fuse
  • Qty: 4 – 5/16″ x 2/0 Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Positive Wire to Starting Battery, Isolator x2, & House Battery Bank
  • Qty: 5 – 16 AWG Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Isolator Ign to Ignition Positive
  • Qty: 1 – Add-a-Fuse Kit
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Used to piggyback power for Ignition+ Wire
  • Qty: 5 – 16 AWG Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Isolator Gnd to Chassis Ground
  • Qty: 10 – 16 AWG Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Isolator Sig to Momentary Switch & from Momentary Switch to Chassis Ground
  • Qty: 1 – Momentary Switch
    • Placed in-line on Isolator Sig Wire
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

Misc Tools & Accessories (As Needed/Optional)
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

Wires, Lugs, Breakers, and Fuses

Wires
Add Wires Individually to Verify Quantities

Lugs
Add Lugs Individually to Verify Quantities

Fuses & Breakers
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

400W Solar | 200Ah Batteries

200Ah Lithium Battery Bank – 4x100W Solar – 2kW Inverter/Charger – Li-BIM Alternator Charging
EXPLORIST.life / Battle Born Solar Bundle [Affiliate Link] 100W Solar Panels [Affiliate Link] 50A ANL Fuse [Affiliate Link] Roof Entry Gland [Affiliate Link] 100A ANL Fuse [Affiliate Link] 250A ANL Fuse [Affiliate Link] 250A ANL Fuse [Affiliate Link] 15A Solar Disconnect [Affiliate Link] Master Battery Disconnect Switch [Affiliate Link] Exterior Shore Power Outlet [Affiliate Link] 250A Terminal Fuse [Affiliate Link] 300A Terminal Fuse [Affiliate Link] 30 A Shore Power Cord [Affiliate Link] 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 8 AWG x 5/16 Wire Lug 6 AWG x 5/16 Wire Lug 8 AWG x 5/16 Wire Lug 8 AWG x 5/16 Wire Lug 6 AWG x 5/16 Wire Lug 8 AWG x 5/16 Wire Lug 2 AWG x 1/4 Wire Lug 2 AWG x 1/4 Wire Lug Tutorial: How to Wire the Li-BIM Battery Isolator Tutorial: How to Wire the AC Side of Your Electrical System Tutorial: How to Wire for Shore Power Tutorial: How to Wire a Battery Bank Tutorial: How to Wire a Busbar Tutorial: How To Wire DC Distribution Block & Accessories Power distribution panel - Amazon Affiliate Link

EXPLORIST.life / Battle Born Solar Bundle [Affiliate Link]

Battery, Inverter, Charge Controller, Battery Monitor Discount Bundle Coming June 1.

100W Solar Panels [Affiliate Link]

50A ANL Fuse [Affiliate Link]

Roof Entry Gland [Affiliate Link]

100A ANL Fuse [Affiliate Link]

250A ANL Fuse [Affiliate Link]

250A ANL Fuse [Affiliate Link]

15A Solar Disconnect [Affiliate Link]

Master Battery Disconnect Switch [Affiliate Link]

Exterior Shore Power Outlet [Affiliate Link]

250A Terminal Fuse [Affiliate Link]

300A Terminal Fuse [Affiliate Link]

30 A Shore Power Cord [Affiliate Link]

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

8 AWG x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

6 AWG x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

8 AWG x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

8 AWG x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

6 AWG x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

8 AWG x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2 AWG x 1/4 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2 AWG x 1/4 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

Tutorial: How to Wire the Li-BIM Battery Isolator

Tutorial: How to Wire the AC Side of Your Electrical System

Tutorial: How to Wire for Shore Power

Tutorial: How to Wire a Battery Bank

Tutorial: How to Wire a Busbar

Tutorial: How To Wire DC Distribution Block & Accessories

Power distribution panel - Amazon Affiliate Link

CLICK HERE TO EXPAND THE SHOPPING LIST FOR DIGRAM ABOVE
SYSTEM STATS:
Solar Array: 400W (4x100W Panels)
Battery Bank: 200Ah (2x100Ah) Lithium – 12V
Inverter: 2000W Pure Sine Wave
Charging: Solar, Shore, Alternator
EXPLORIST.life Battery, Charge Controller, Inverter Bundle
Solar Charging System:
  • Qty: 4 – 100 Watt Solar Panel
    • Put these in the sun
  • Qty: 4 – Solar Panel Mounting Feet
    • Help mount solar panels to the roof
  • Qty: 1 – MC4 Connectors
    • Connecting Solar Panels to Wires going to Charge Controller
  • Qty: 40 – 10 AWG Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Solar Panel to Charge Controller
  • Qty: 40 – 10 AWG Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Solar Panel to Charge Controller
  • Qty: 1 – Roof Entry Gland
    • Waterproof Box for Running Wires through Roof
  • Qty: 1 – 1″ Wire Grommet
    • Mounted in roof under Roof Entry Gland
  • Qty: 1 – 15 Amp Solar Disconnect Switch
    • Mounted on Din Rail Between Solar Panels & Solar Contoller
  • Qty: 1 – Din Rail
    • To mount the Solar Disconnect Switch
  • Qty: 1 – Victron Smartsolar MPPT 150 | 35 – Bundle
    • Included in Bundle at Top of List
    • Solar Charge Controller
  • Qty: 5 – 8 AWG Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Charge Controller to Busbar
  • Qty: 5 – 8 AWG Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between Busbar & Charge Controller Equipment Ground
  • Qty: 5 – 8 AWG Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Charge Controller to Busbar
  • Qty: 2 – 5/16″ x 8 AWG Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Positive & Negative Wires from Charge Controller to Busbar
  • Qty: 2 – 5/16″ x 8 AWG Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Connecting Busbar to Charge Controller Equipment Ground
  • Qty: 1 – 50 Amp ANL Fuse
    • Check Wire, Lug, and Fuse List at Bottom of List
    • On Positive Busbar Protecting Red Wire to Charge Controller
  • Qty: 1 – ANL Fuse Holder
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Mounted to Busbar under each ANL fuse
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

Battery Bank, Busbar, & Inverter
  • Qty: 1 – 2000W Victron MultiPlus Compact Inverter Charger 12V – Bundle
    • Included in Bundle at Top of List
    • This Converts Your 12v DC Power to 120v AC Power
  • Qty: 1 – 200Ah Battle Born Lithium Battery Bundle
    • Included in Bundle at Top of List
    • These Store Your Power
  • Qty: 4 – 2/0 Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between Batteries & From Batteries to Busbar
  • Qty: 4 – 2/0 Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between Batteries & From Batteries to Busbar
  • Qty: 8 – 5/16″ x 2/0 Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Wires to Batteries & to Busbar
  • Qty: 1 – 300 Amp Terminal Fuse
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attached to Battery Protecting Red Wire to Busbar
  • Qty: 5 – 2/0 Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between Busbar & Inverter
  • Qty: 5 – 2/0 Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between Busbar & Inverter
  • Qty: 5 – 2/0 Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between Busbar & Inverter Equipment Ground
  • Qty: 5 – 2/0 Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between Busbar & Chassis Ground
  • Qty: 2 – 5/16″ x 2/0 Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Positive Wire from Busbar to Inverter
  • Qty: 2 – 5/16″ x 2/0 Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Negative Wire from Busbar to Inverter
  • Qty: 2 – 5/16″ x 2/0 Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Black Wire from Negative Busbar to Inverter Equipment Ground
  • Qty: 2 – 5/16″ x 2/0 Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Black Wire from Negative Busbar to Vehicle Chassis Ground
  • Qty: 1 – 250 Amp ANL Fuse
    • Check Wire, Lug, and Fuse List at Bottom of List
    • On Positive Busbar Protecting Red Wire to Inverter
  • Qty: 1 – ANL Fuse Holder
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Mounted to Busbar under each ANL fuse
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

DC Busbar
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

AC Circuits & Shore Power
  • Qty: 1 – 30 Amp Shore Power Cord
    • Connecting 30A Flanged Power Inlet to Shore Power
  • Qty: 1 – 30 Amp Shore Power Extension Cord
    • If your Shore Power Cord is too Short
  • Qty: 1 – 30A to 15A Adapter
    • For plugging your 30A shore power cord into a 15/20 amp standard outlet.
  • Qty: 1 – 30A Flanged Power Inlet
    • Connected to Outside of Camper
  • Qty: 10 – 10 AWG 3 Conductor Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From 30A Flanged Power Inlet to Inverter
  • Qty: 5 – 6 AWG 3 Conductor Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Inverter to Power Distribution Panel
  • Qty: 1 – Power Distribution Panel
    • For Distributing Power & Housing Breakers/Fuses
  • Qty: 1 – 50A AC Breaker
    • Check Wire, Lug, and Fuse List at Bottom of List
    • For AC Branch Circuits
  • Qty: 1 – 20A HOMT Tandem AC Breaker
    • Check Wire, Lug, and Fuse List at Bottom of List
    • For Standard 120V Outlet Circuits
  • Qty: 1 – 20A / 30A HOMT Tandem AC Breaker
    • Check Wire, Lug, and Fuse List at Bottom of List
    • For Circuits that include large loads (hot water heater)
  • Qty: 50 – 12 AWG 3 Conductor Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • For AC Branch Circuits
  • Qty: 6 – 120V GFCI Outlet
    • For plugging 120V Appliances into
  • Qty: 6 – Single Gang Electrical Box
    • For 120V GFCI Outlet
  • Qty: 6 – GFCI Wall Plates
    • For 120V GFCI Outlet
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

12v Distribution
  • Qty: 1 – Power Distribution Panel
    • For Distributing Power & Housing Breakers/Fuses
  • Qty: 1 – 100 AMP ANL Fuse
    • Check Wire, Lug, and Fuse List at Bottom of List
    • On Positive Busbar Protecting Red Wire to the Power Distribution Panel
  • Qty: 1 – ANL Fuse Holder
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Mounted to Busbar under each ANL fuse
  • Qty: 2 – 5/16″ x 6 AWG Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Positive & Negatives Wires to the Busbar from the Power Distribution Panel
  • Qty: 5 – 6 AWG Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Positive Wire From Busbar to Power Distribution Panel
  • Qty: 5 – 6 AWG Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Negative Wire From Busbar to Power Distribution Panel
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

Alternator Charging
  • Qty: – LI-BIM 225 Isolator
    • Connects and Disconnects House and Starting Battery Banks
  • Qty: 5 – 2/0 Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between LI-BIM 225 Isolator & Start Battery
  • Qty: 20 – 2/0 Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between LI-BIM 225 Isolator & House Battery Bank
  • Qty: 1 – 250 Amp Terminal Fuse
    • Check Wire, Lug, and Fuse List at Bottom of List
    • On Starting Battery Protecting Red Wire to LI-BIM 225 Isolator
  • Qty: 1 – 250 Amp ANL Fuse
    • Check Wire, Lug, and Fuse List at Bottom of List
    • On Positive Busbar Protecting Red Wire to LI-BIM 225 Isolator
  • Qty: 1 – ANL Fuse Holder
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Mounted to Busbar under each ANL fuse
  • Qty: 4 – 5/16″ x 2/0 Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Positive Wire to Starting Battery, Isolator x2, & House Battery Bank
  • Qty: 5 – 16 AWG Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Isolator Ign to Ignition Positive
  • Qty: 1 – Add-a-Fuse Kit
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Used to piggyback power for Ignition+ Wire
  • Qty: 5 – 16 AWG Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Isolator Gnd to Chassis Ground
  • Qty: 10 – 16 AWG Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Isolator Sig to Momentary Switch & from Momentary Switch to Chassis Ground
  • Qty: 1 – Momentary Switch
    • Placed in-line on Isolator Sig Wire
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

Misc Tools & Accessories (As Needed/Optional)
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

Wires, Lugs, Breakers, and Fuses

Wires
Add Wires Individually to Verify Quantities

Lugs
Add Lugs Individually to Verify Quantities

Fuses & Breakers
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

350W Solar | 400Ah Batteries

400Ah Lithium Battery Bank – 2x175W Solar – 2kW Inverter/Charger – Li-BIM Alternator Charging
EXPLORIST.life / Battle Born Solar Bundle [Affiliate Link] 175W Solar Panels [Affiliate Link] 50A ANL Fuse [Affiliate Link] Roof Entry Gland [Affiliate Link] 100A ANL Fuse [Affiliate Link] 250A ANL Fuse [Affiliate Link] 250A ANL Fuse [Affiliate Link] 15A Solar Disconnect [Affiliate Link] Master Battery Disconnect Switch [Affiliate Link] Exterior Shore Power Outlet [Affiliate Link] 250A Terminal Fuse [Affiliate Link] 300A Terminal Fuse [Affiliate Link] 30 A Shore Power Cord [Affiliate Link] 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 8 AWG x 5/16 Wire Lug 6 AWG x 5/16 Wire Lug 8 AWG x 5/16 Wire Lug 8 AWG x 5/16 Wire Lug 6 AWG x 5/16 Wire Lug 8 AWG x 5/16 Wire Lug Tutorial: How to Wire the Li-BIM Battery Isolator Tutorial: How to Wire the AC Side of Your Electrical System Tutorial: How to Wire for Shore Power Tutorial: How to Wire a Battery Bank Tutorial: How to Wire a Busbar Tutorial: How To Wire DC Distribution Block & Accessories Tutorial: How to wire a power distribution panel

EXPLORIST.life / Battle Born Solar Bundle [Affiliate Link]

Battery, Inverter, Charge Controller, Battery Monitor Discount Bundle Coming June 1.

175W Solar Panels [Affiliate Link]

50A ANL Fuse [Affiliate Link]

Roof Entry Gland [Affiliate Link]

100A ANL Fuse [Affiliate Link]

250A ANL Fuse [Affiliate Link]

250A ANL Fuse [Affiliate Link]

15A Solar Disconnect [Affiliate Link]

Master Battery Disconnect Switch [Affiliate Link]

Exterior Shore Power Outlet [Affiliate Link]

250A Terminal Fuse [Affiliate Link]

300A Terminal Fuse [Affiliate Link]

30 A Shore Power Cord [Affiliate Link]

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

8 AWG x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

6 AWG x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

8 AWG x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

8 AWG x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

6 AWG x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

8 AWG x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

Tutorial: How to Wire the Li-BIM Battery Isolator

Tutorial: How to Wire the AC Side of Your Electrical System

Tutorial: How to Wire for Shore Power

Tutorial: How to Wire a Battery Bank

Tutorial: How to Wire a Busbar

Tutorial: How To Wire DC Distribution Block & Accessories

Tutorial: How to wire a power distribution panel

CLICK HERE TO EXPAND THE SHOPPING LIST FOR DIGRAM ABOVE
SYSTEM STATS:
Solar Array: 350W (2x175W Panels)
Battery Bank: 400Ah (4x100Ah) Lithium – 12V
Inverter: 2000W Pure Sine Wave
Charging: Solar, Shore, Alternator
EXPLORIST.life Battery, Charge Controller, Inverter Bundle
Solar Charging System:
  • Qty: 2 – 175 Watt Solar Panel
    • Put these in the sun
  • Qty: 2 – Solar Panel Mounting Feet
    • Help mount solar panels to the roof
  • Qty: 1 – MC4 Connectors
    • Connecting Solar Panels to Wires going to Charge Controller
  • Qty: 40 – 10 AWG Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Solar Panel to Charge Controller
  • Qty: 40 – 10 AWG Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Solar Panel to Charge Controller
  • Qty: 1 – Roof Entry Gland
    • Waterproof Box for Running Wires through Roof
  • Qty: 1 – 1″ Wire Grommet
    • Mounted in roof under Roof Entry Gland
  • Qty: 1 – 15 Amp Solar Disconnect Switch
    • Mounted on Din Rail Between Solar Panels & Solar Contoller
  • Qty: 1 – Din Rail
    • To mount the Solar Disconnect Switch
  • Qty: 1 – Victron Smartsolar MPPT 150 | 35 – Bundle
    • Included in Bundle at Top of List
    • Solar Charge Controller
  • Qty: 5 – 8 AWG Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Charge Controller to Busbar
  • Qty: 5 – 8 AWG Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between Busbar & Charge Controller Equipment Ground
  • Qty: 5 – 8 AWG Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Charge Controller to Busbar
  • Qty: 2 – 5/16″ x 8 AWG Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Positive & Negative Wires from Charge Controller to Busbar
  • Qty: 2 – 5/16″ x 8 AWG Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Connecting Busbar to Charge Controller Equipment Ground
  • Qty: 1 – 50 Amp ANL Fuse
    • Check Wire, Lug, and Fuse List at Bottom of List
    • On Positive Busbar Protecting Red Wire to Charge Controller
  • Qty: 1 – ANL Fuse Holder
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Mounted to Busbar under each ANL fuse
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

Battery Bank, Busbar, & Inverter
  • Qty: 1 – 2000W Victron MultiPlus Compact Inverter Charger 12V – Bundle
    • Included in Bundle at Top of List
    • This Converts Your 12v DC Power to 120v AC Power
  • Qty: 1 – 400Ah Battle Born Lithium Battery Bundle
    • Included in Bundle at Top of List
    • These Store Your Power
  • Qty: 6 – 2/0 Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between Batteries & From Batteries to Busbar
  • Qty: 6 – 2/0 Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between Batteries & From Batteries to Busbar
  • Qty: 16 – 5/16″ x 2/0 Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Wires to Batteries & to Busbar
  • Qty: 1 – 300 Amp Terminal Fuse
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attached to Battery Protecting Red Wire to Busbar
  • Qty: 5 – 2/0 Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between Busbar & Inverter
  • Qty: 5 – 2/0 Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between Busbar & Inverter
  • Qty: 5 – 2/0 Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between Busbar & Inverter Equipment Ground
  • Qty: 5 – 2/0 Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between Busbar & Chassis Ground
  • Qty: 2 – 5/16″ x 2/0 Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Positive Wire from Busbar to Inverter
  • Qty: 2 – 5/16″ x 2/0 Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Negative Wire from Busbar to Inverter
  • Qty: 2 – 5/16″ x 2/0 Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Black Wire from Negative Busbar to Inverter Equipment Ground
  • Qty: 2 – 5/16″ x 2/0 Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Black Wire from Negative Busbar to Vehicle Chassis Ground
  • Qty: 1 – 250 Amp ANL Fuse
    • Check Wire, Lug, and Fuse List at Bottom of List
    • On Positive Busbar Protecting Red Wire to Inverter
  • Qty: 1 – ANL Fuse Holder
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Mounted to Busbar under each ANL fuse
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

DC Busbar
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

AC Circuits & Shore Power
  • Qty: 1 – 30 Amp Shore Power Cord
    • Connecting 30A Flanged Power Inlet to Shore Power
  • Qty: 1 – 30 Amp Shore Power Extension Cord
    • If your Shore Power Cord is too Short
  • Qty: 1 – 30A to 15A Adapter
    • For plugging your 30A shore power cord into a 15/20 amp standard outlet.
  • Qty: 1 – 30A Flanged Power Inlet
    • Connected to Outside of Camper
  • Qty: 10 – 10 AWG 3 Conductor Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From 30A Flanged Power Inlet to Inverter
  • Qty: 5 – 6 AWG 3 Conductor Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Inverter to Power Distribution Panel
  • Qty: 1 – Power Distribution Panel
    • For Distributing Power & Housing Breakers/Fuses
  • Qty: 1 – 50A AC Breaker
    • Check Wire, Lug, and Fuse List at Bottom of List
    • For AC Branch Circuits
  • Qty: 1 – 20A HOMT Tandem AC Breaker
    • Check Wire, Lug, and Fuse List at Bottom of List
    • For Standard 120V Outlet Circuits
  • Qty: 1 – 20A / 30A HOMT Tandem AC Breaker
    • Check Wire, Lug, and Fuse List at Bottom of List
    • For Circuits that include large loads (hot water heater)
  • Qty: 50 – 12 AWG 3 Conductor Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • For AC Branch Circuits
  • Qty: 6 – 120V GFCI Outlet
    • For plugging 120V Appliances into
  • Qty: 6 – Single Gang Electrical Box
    • For 120V GFCI Outlet
  • Qty: 6 – GFCI Wall Plates
    • For 120V GFCI Outlet
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

12v Distribution
  • Qty: 1 – Power Distribution Panel
    • For Distributing Power & Housing Breakers/Fuses
  • Qty: 1 – 100 AMP ANL Fuse
    • Check Wire, Lug, and Fuse List at Bottom of List
    • On Positive Busbar Protecting Red Wire to the Power Distribution Panel
  • Qty: 1 – ANL Fuse Holder
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Mounted to Busbar under each ANL fuse
  • Qty: 2 – 5/16″ x 6 AWG Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Positive & Negatives Wires to the Busbar from the Power Distribution Panel
  • Qty: 5 – 6 AWG Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Positive Wire From Busbar to Power Distribution Panel
  • Qty: 5 – 6 AWG Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Negative Wire From Busbar to Power Distribution Panel
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

Alternator Charging
  • Qty: – LI-BIM 225 Isolator
    • Connects and Disconnects House and Starting Battery Banks
  • Qty: 5 – 2/0 Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between LI-BIM 225 Isolator & Start Battery
  • Qty: 20 – 2/0 Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between LI-BIM 225 Isolator & House Battery Bank
  • Qty: 1 – 250 Amp Terminal Fuse
    • Check Wire, Lug, and Fuse List at Bottom of List
    • On Starting Battery Protecting Red Wire to LI-BIM 225 Isolator
  • Qty: 1 – 250 Amp ANL Fuse
    • Check Wire, Lug, and Fuse List at Bottom of List
    • On Positive Busbar Protecting Red Wire to LI-BIM 225 Isolator
  • Qty: 1 – ANL Fuse Holder
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Mounted to Busbar under each ANL fuse
  • Qty: 4 – 5/16″ x 2/0 Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Positive Wire to Starting Battery, Isolator x2, & House Battery Bank
  • Qty: 5 – 16 AWG Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Isolator Ign to Ignition Positive
  • Qty: 1 – Add-a-Fuse Kit
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Used to piggyback power for Ignition+ Wire
  • Qty: 5 – 16 AWG Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Isolator Gnd to Chassis Ground
  • Qty: 10 – 16 AWG Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Isolator Sig to Momentary Switch & from Momentary Switch to Chassis Ground
  • Qty: 1 – Momentary Switch
    • Placed in-line on Isolator Sig Wire
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

Misc Tools & Accessories (As Needed/Optional)
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

Wires, Lugs, Breakers, and Fuses

Wires
Add Wires Individually to Verify Quantities

Lugs
Add Lugs Individually to Verify Quantities

Fuses & Breakers
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

350W Solar | 300Ah Batteries

300Ah Lithium Battery Bank – 2x175W Solar – 2kW Inverter/Charger – Li-BIM Alternator Charging
EXPLORIST.life / Battle Born Solar Bundle [Affiliate Link] 175W Solar Panels [Affiliate Link] 50A ANL Fuse [Affiliate Link] Roof Entry Gland [Affiliate Link] 100A ANL Fuse [Affiliate Link] 250A ANL Fuse [Affiliate Link] 250A ANL Fuse [Affiliate Link] 15A Solar Disconnect [Affiliate Link] Master Battery Disconnect Switch [Affiliate Link] Exterior Shore Power Outlet [Affiliate Link] 250A Terminal Fuse [Affiliate Link] 300A Terminal Fuse [Affiliate Link] 30 A Shore Power Cord [Affiliate Link] 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 8 AWG x 5/16 Wire Lug 6 AWG x 5/16 Wire Lug 8 AWG x 5/16 Wire Lug 8 AWG x 5/16 Wire Lug 6 AWG x 5/16 Wire Lug 8 AWG x 5/16 Wire Lug Tutorial: How to Wire the Li-BIM Battery Isolator Tutorial: How to Wire the AC Side of Your Electrical System Tutorial: How to Wire for Shore Power Tutorial: How to Wire a Battery Bank Tutorial: How to Wire a Busbar Tutorial: How To Wire DC Distribution Block & Accessories Power Distribution Panel - Amazon Affiliate Link

EXPLORIST.life / Battle Born Solar Bundle [Affiliate Link]

Battery, Inverter, Charge Controller, Battery Monitor Discount Bundle Coming June 1.

175W Solar Panels [Affiliate Link]

50A ANL Fuse [Affiliate Link]

Roof Entry Gland [Affiliate Link]

100A ANL Fuse [Affiliate Link]

250A ANL Fuse [Affiliate Link]

250A ANL Fuse [Affiliate Link]

15A Solar Disconnect [Affiliate Link]

Master Battery Disconnect Switch [Affiliate Link]

Exterior Shore Power Outlet [Affiliate Link]

250A Terminal Fuse [Affiliate Link]

300A Terminal Fuse [Affiliate Link]

30 A Shore Power Cord [Affiliate Link]

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

8 AWG x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

6 AWG x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

8 AWG x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

8 AWG x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

6 AWG x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

8 AWG x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

Tutorial: How to Wire the Li-BIM Battery Isolator

Tutorial: How to Wire the AC Side of Your Electrical System

Tutorial: How to Wire for Shore Power

Tutorial: How to Wire a Battery Bank

Tutorial: How to Wire a Busbar

Tutorial: How To Wire DC Distribution Block & Accessories

Power Distribution Panel - Amazon Affiliate Link

CLICK HERE TO EXPAND THE SHOPPING LIST FOR DIGRAM ABOVE
SYSTEM STATS:
Solar Array: 350W (2x175W Panels)
Battery Bank: 300Ah (3x100Ah) Lithium – 12V
Inverter: 2000W Pure Sine Wave
Charging: Solar, Shore, Alternator
EXPLORIST.life Battery, Charge Controller, Inverter Bundle
Solar Charging System:
  • Qty: 2 – 175 Watt Solar Panel
    • Put these in the sun
  • Qty: 2 – Solar Panel Mounting Feet
    • Help mount solar panels to the roof
  • Qty: 1 – MC4 Connectors
    • Connecting Solar Panels to Wires going to Charge Controller
  • Qty: 40 – 10 AWG Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Solar Panel to Charge Controller
  • Qty: 40 – 10 AWG Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Solar Panel to Charge Controller
  • Qty: 1 – Roof Entry Gland
    • Waterproof Box for Running Wires through Roof
  • Qty: 1 – 1″ Wire Grommet
    • Mounted in roof under Roof Entry Gland
  • Qty: 1 – 15 Amp Solar Disconnect Switch
    • Mounted on Din Rail Between Solar Panels & Solar Contoller
  • Qty: 1 – Din Rail
    • To mount the Solar Disconnect Switch
  • Qty: 1 – Victron Smartsolar MPPT 150 | 35 – Bundle
    • Included in Bundle at Top of List
    • Solar Charge Controller
  • Qty: 5 – 8 AWG Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Charge Controller to Busbar
  • Qty: 5 – 8 AWG Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between Busbar & Charge Controller Equipment Ground
  • Qty: 5 – 8 AWG Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Charge Controller to Busbar
  • Qty: 2 – 5/16″ x 8 AWG Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Positive & Negative Wires from Charge Controller to Busbar
  • Qty: 2 – 5/16″ x 8 AWG Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Connecting Busbar to Charge Controller Equipment Ground
  • Qty: 1 – 50 Amp ANL Fuse
    • Check Wire, Lug, and Fuse List at Bottom of List
    • On Positive Busbar Protecting Red Wire to Charge Controller
  • Qty: 1 – ANL Fuse Holder
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Mounted to Busbar under each ANL fuse
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

Battery Bank, Busbar, & Inverter
  • Qty: 1 – 2000W Victron MultiPlus Compact Inverter Charger 12V – Bundle
    • Included in Bundle at Top of List
    • This Converts Your 12v DC Power to 120v AC Power
  • Qty: 1 – 300Ah Battle Born Lithium Battery Bundle
    • Included in Bundle at Top of List
    • These Store Your Power
  • Qty: 5 – 2/0 Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between Batteries & From Batteries to Busbar
  • Qty: 5 – 2/0 Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between Batteries & From Batteries to Busbar
  • Qty: 12 – 5/16″ x 2/0 Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Wires to Batteries & to Busbar
  • Qty: 1 – 300 Amp Terminal Fuse
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attached to Battery Protecting Red Wire to Busbar
  • Qty: 5 – 2/0 Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between Busbar & Inverter
  • Qty: 5 – 2/0 Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between Busbar & Inverter
  • Qty: 5 – 2/0 Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between Busbar & Inverter Equipment Ground
  • Qty: 5 – 2/0 Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between Busbar & Chassis Ground
  • Qty: 2 – 5/16″ x 2/0 Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Positive Wire from Busbar to Inverter
  • Qty: 2 – 5/16″ x 2/0 Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Negative Wire from Busbar to Inverter
  • Qty: 2 – 5/16″ x 2/0 Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Black Wire from Negative Busbar to Inverter Equipment Ground
  • Qty: 2 – 5/16″ x 2/0 Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Black Wire from Negative Busbar to Vehicle Chassis Ground
  • Qty: 1 – 250 Amp ANL Fuse
    • Check Wire, Lug, and Fuse List at Bottom of List
    • On Positive Busbar Protecting Red Wire to Inverter
  • Qty: 1 – ANL Fuse Holder
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Mounted to Busbar under each ANL fuse
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

DC Busbar
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

AC Circuits & Shore Power
  • Qty: 1 – 30 Amp Shore Power Cord
    • Connecting 30A Flanged Power Inlet to Shore Power
  • Qty: 1 – 30 Amp Shore Power Extension Cord
    • If your Shore Power Cord is too Short
  • Qty: 1 – 30A to 15A Adapter
    • For plugging your 30A shore power cord into a 15/20 amp standard outlet.
  • Qty: 1 – 30A Flanged Power Inlet
    • Connected to Outside of Camper
  • Qty: 10 – 10 AWG 3 Conductor Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From 30A Flanged Power Inlet to Inverter
  • Qty: 5 – 6 AWG 3 Conductor Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Inverter to Power Distribution Panel
  • Qty: 1 – Power Distribution Panel
    • For Distributing Power & Housing Breakers/Fuses
  • Qty: 1 – 50A AC Breaker
    • Check Wire, Lug, and Fuse List at Bottom of List
    • For AC Branch Circuits
  • Qty: 1 – 20A HOMT Tandem AC Breaker
    • Check Wire, Lug, and Fuse List at Bottom of List
    • For Standard 120V Outlet Circuits
  • Qty: 1 – 20A / 30A HOMT Tandem AC Breaker
    • Check Wire, Lug, and Fuse List at Bottom of List
    • For Circuits that include large loads (hot water heater)
  • Qty: 50 – 12 AWG 3 Conductor Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • For AC Branch Circuits
  • Qty: 6 – 120V GFCI Outlet
    • For plugging 120V Appliances into
  • Qty: 6 – Single Gang Electrical Box
    • For 120V GFCI Outlet
  • Qty: 6 – GFCI Wall Plates
    • For 120V GFCI Outlet
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

12v Distribution
  • Qty: 1 – Power Distribution Panel
    • For Distributing Power & Housing Breakers/Fuses
  • Qty: 1 – 100 AMP ANL Fuse
    • Check Wire, Lug, and Fuse List at Bottom of List
    • On Positive Busbar Protecting Red Wire to the Power Distribution Panel
  • Qty: 1 – ANL Fuse Holder
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Mounted to Busbar under each ANL fuse
  • Qty: 2 – 5/16″ x 6 AWG Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Positive & Negatives Wires to the Busbar from the Power Distribution Panel
  • Qty: 5 – 6 AWG Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Positive Wire From Busbar to Power Distribution Panel
  • Qty: 5 – 6 AWG Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Negative Wire From Busbar to Power Distribution Panel
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

Alternator Charging
  • Qty: – LI-BIM 225 Isolator
    • Connects and Disconnects House and Starting Battery Banks
  • Qty: 5 – 2/0 Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between LI-BIM 225 Isolator & Start Battery
  • Qty: 20 – 2/0 Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between LI-BIM 225 Isolator & House Battery Bank
  • Qty: 1 – 250 Amp Terminal Fuse
    • Check Wire, Lug, and Fuse List at Bottom of List
    • On Starting Battery Protecting Red Wire to LI-BIM 225 Isolator
  • Qty: 1 – 250 Amp ANL Fuse
    • Check Wire, Lug, and Fuse List at Bottom of List
    • On Positive Busbar Protecting Red Wire to LI-BIM 225 Isolator
  • Qty: 1 – ANL Fuse Holder
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Mounted to Busbar under each ANL fuse
  • Qty: 4 – 5/16″ x 2/0 Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Positive Wire to Starting Battery, Isolator x2, & House Battery Bank
  • Qty: 5 – 16 AWG Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Isolator Ign to Ignition Positive
  • Qty: 1 – Add-a-Fuse Kit
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Used to piggyback power for Ignition+ Wire
  • Qty: 5 – 16 AWG Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Isolator Gnd to Chassis Ground
  • Qty: 10 – 16 AWG Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Isolator Sig to Momentary Switch & from Momentary Switch to Chassis Ground
  • Qty: 1 – Momentary Switch
    • Placed in-line on Isolator Sig Wire
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

Misc Tools & Accessories (As Needed/Optional)
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

Wires, Lugs, Breakers, and Fuses

Wires
Add Wires Individually to Verify Quantities

Lugs
Add Lugs Individually to Verify Quantities

Fuses & Breakers
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

350W Solar | 200Ah Batteries

200Ah Lithium Battery Bank – 2x175W Solar – 2kW Inverter/Charger – Li-BIM Alternator Charging
EXPLORIST.life / Battle Born Solar Bundle [Affiliate Link] 175W Solar Panels [Affiliate Link] 50A ANL Fuse [Affiliate Link] Roof Entry Gland [Affiliate Link] 100A ANL Fuse [Affiliate Link] 250A ANL Fuse [Affiliate Link] 250A ANL Fuse [Affiliate Link] 15A Solar Disconnect [Affiliate Link] Master Battery Disconnect Switch [Affiliate Link] Exterior Shore Power Outlet [Affiliate Link] 250A Terminal Fuse [Affiliate Link] 300A Terminal Fuse [Affiliate Link] 30 A Shore Power Cord [Affiliate Link] 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 8 AWG x 5/16 Wire Lug 6 AWG x 5/16 Wire Lug 8 AWG x 5/16 Wire Lug 8 AWG x 5/16 Wire Lug 6 AWG x 5/16 Wire Lug 8 AWG x 5/16 Wire Lug Tutorial: How to Wire the Li-BIM Battery Isolator Tutorial: How to Wire the AC Side of Your Electrical System Tutorial: How to Wire for Shore Power Tutorial: How to Wire a Battery Bank Tutorial: How to Wire a Busbar Tutorial: How To Wire DC Distribution Block & Accessories Tutorial: How to wire a power distribution panel

EXPLORIST.life / Battle Born Solar Bundle [Affiliate Link]

Battery, Inverter, Charge Controller, Battery Monitor Discount Bundle Coming June 1.

175W Solar Panels [Affiliate Link]

50A ANL Fuse [Affiliate Link]

Roof Entry Gland [Affiliate Link]

100A ANL Fuse [Affiliate Link]

250A ANL Fuse [Affiliate Link]

250A ANL Fuse [Affiliate Link]

15A Solar Disconnect [Affiliate Link]

Master Battery Disconnect Switch [Affiliate Link]

Exterior Shore Power Outlet [Affiliate Link]

250A Terminal Fuse [Affiliate Link]

300A Terminal Fuse [Affiliate Link]

30 A Shore Power Cord [Affiliate Link]

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

8 AWG x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

6 AWG x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

8 AWG x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

8 AWG x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

6 AWG x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

8 AWG x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

Tutorial: How to Wire the Li-BIM Battery Isolator

Tutorial: How to Wire the AC Side of Your Electrical System

Tutorial: How to Wire for Shore Power

Tutorial: How to Wire a Battery Bank

Tutorial: How to Wire a Busbar

Tutorial: How To Wire DC Distribution Block & Accessories

Tutorial: How to wire a power distribution panel

CLICK HERE TO EXPAND THE SHOPPING LIST FOR DIGRAM ABOVE
SYSTEM STATS:
Solar Array: 350W (2x175W Panels)
Battery Bank: 200Ah (2x100Ah) Lithium – 12V
Inverter: 2000W Pure Sine Wave
Charging: Solar, Shore, Alternator
EXPLORIST.life Battery, Charge Controller, Inverter Bundle
Solar Charging System:
  • Qty: 2 – 175 Watt Solar Panel
    • Put these in the sun
  • Qty: 2 – Solar Panel Mounting Feet
    • Help mount solar panels to the roof
  • Qty: 1 – MC4 Connectors
    • Connecting Solar Panels to Wires going to Charge Controller
  • Qty: 40 – 10 AWG Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Solar Panel to Charge Controller
  • Qty: 40 – 10 AWG Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Solar Panel to Charge Controller
  • Qty: 1 – Roof Entry Gland
    • Waterproof Box for Running Wires through Roof
  • Qty: 1 – 1″ Wire Grommet
    • Mounted in roof under Roof Entry Gland
  • Qty: 1 – 15 Amp Solar Disconnect Switch
    • Mounted on Din Rail Between Solar Panels & Solar Contoller
  • Qty: 1 – Din Rail
    • To mount the Solar Disconnect Switch
  • Qty: 1 – Victron Smartsolar MPPT 150 | 35 – Bundle
    • Included in Bundle at Top of List
    • Solar Charge Controller
  • Qty: 5 – 8 AWG Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Charge Controller to Busbar
  • Qty: 5 – 8 AWG Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between Busbar & Charge Controller Equipment Ground
  • Qty: 5 – 8 AWG Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Charge Controller to Busbar
  • Qty: 2 – 5/16″ x 8 AWG Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Positive & Negative Wires from Charge Controller to Busbar
  • Qty: 2 – 5/16″ x 8 AWG Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Connecting Busbar to Charge Controller Equipment Ground
  • Qty: 1 – 50 Amp ANL Fuse
    • Check Wire, Lug, and Fuse List at Bottom of List
    • On Positive Busbar Protecting Red Wire to Charge Controller
  • Qty: 1 – ANL Fuse Holder
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Mounted to Busbar under each ANL fuse
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

Battery Bank, Busbar, & Inverter
  • Qty: 1 – 2000W Victron MultiPlus Compact Inverter Charger 12V – Bundle
    • Included in Bundle at Top of List
    • This Converts Your 12v DC Power to 120v AC Power
  • Qty: 1 – 200Ah Battle Born Lithium Battery Bundle
    • Included in Bundle at Top of List
    • These Store Your Power
  • Qty: 4 – 2/0 Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between Batteries & From Batteries to Busbar
  • Qty: 4 – 2/0 Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between Batteries & From Batteries to Busbar
  • Qty: 8 – 5/16″ x 2/0 Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Wires to Batteries & to Busbar
  • Qty: 1 – 300 Amp Terminal Fuse
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attached to Battery Protecting Red Wire to Busbar
  • Qty: 5 – 2/0 Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between Busbar & Inverter
  • Qty: 5 – 2/0 Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between Busbar & Inverter
  • Qty: 5 – 2/0 Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between Busbar & Inverter Equipment Ground
  • Qty: 5 – 2/0 Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between Busbar & Chassis Ground
  • Qty: 2 – 5/16″ x 2/0 Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Positive Wire from Busbar to Inverter
  • Qty: 2 – 5/16″ x 2/0 Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Negative Wire from Busbar to Inverter
  • Qty: 2 – 5/16″ x 2/0 Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Black Wire from Negative Busbar to Inverter Equipment Ground
  • Qty: 2 – 5/16″ x 2/0 Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Black Wire from Negative Busbar to Vehicle Chassis Ground
  • Qty: 1 – 250 Amp ANL Fuse
    • Check Wire, Lug, and Fuse List at Bottom of List
    • On Positive Busbar Protecting Red Wire to Inverter
  • Qty: 1 – ANL Fuse Holder
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Mounted to Busbar under each ANL fuse
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

DC Busbar
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

AC Circuits & Shore Power
  • Qty: 1 – 30 Amp Shore Power Cord
    • Connecting 30A Flanged Power Inlet to Shore Power
  • Qty: 1 – 30 Amp Shore Power Extension Cord
    • If your Shore Power Cord is too Short
  • Qty: 1 – 30A to 15A Adapter
    • For plugging your 30A shore power cord into a 15/20 amp standard outlet.
  • Qty: 1 – 30A Flanged Power Inlet
    • Connected to Outside of Camper
  • Qty: 10 – 10 AWG 3 Conductor Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From 30A Flanged Power Inlet to Inverter
  • Qty: 5 – 6 AWG 3 Conductor Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Inverter to Power Distribution Panel
  • Qty: 1 – Power Distribution Panel
    • For Distributing Power & Housing Breakers/Fuses
  • Qty: 1 – 50A AC Breaker
    • Check Wire, Lug, and Fuse List at Bottom of List
    • For AC Branch Circuits
  • Qty: 1 – 20A HOMT Tandem AC Breaker
    • Check Wire, Lug, and Fuse List at Bottom of List
    • For Standard 120V Outlet Circuits
  • Qty: 1 – 20A / 30A HOMT Tandem AC Breaker
    • Check Wire, Lug, and Fuse List at Bottom of List
    • For Circuits that include large loads (hot water heater)
  • Qty: 50 – 12 AWG 3 Conductor Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • For AC Branch Circuits
  • Qty: 6 – 120V GFCI Outlet
    • For plugging 120V Appliances into
  • Qty: 6 – Single Gang Electrical Box
    • For 120V GFCI Outlet
  • Qty: 6 – GFCI Wall Plates
    • For 120V GFCI Outlet
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

12v Distribution
  • Qty: 1 – Power Distribution Panel
    • For Distributing Power & Housing Breakers/Fuses
  • Qty: 1 – 100 AMP ANL Fuse
    • Check Wire, Lug, and Fuse List at Bottom of List
    • On Positive Busbar Protecting Red Wire to the Power Distribution Panel
  • Qty: 1 – ANL Fuse Holder
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Mounted to Busbar under each ANL fuse
  • Qty: 2 – 5/16″ x 6 AWG Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Positive & Negatives Wires to the Busbar from the Power Distribution Panel
  • Qty: 5 – 6 AWG Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Positive Wire From Busbar to Power Distribution Panel
  • Qty: 5 – 6 AWG Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Negative Wire From Busbar to Power Distribution Panel
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

Alternator Charging
  • Qty: – LI-BIM 225 Isolator
    • Connects and Disconnects House and Starting Battery Banks
  • Qty: 5 – 2/0 Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between LI-BIM 225 Isolator & Start Battery
  • Qty: 20 – 2/0 Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between LI-BIM 225 Isolator & House Battery Bank
  • Qty: 1 – 250 Amp Terminal Fuse
    • Check Wire, Lug, and Fuse List at Bottom of List
    • On Starting Battery Protecting Red Wire to LI-BIM 225 Isolator
  • Qty: 1 – 250 Amp ANL Fuse
    • Check Wire, Lug, and Fuse List at Bottom of List
    • On Positive Busbar Protecting Red Wire to LI-BIM 225 Isolator
  • Qty: 1 – ANL Fuse Holder
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Mounted to Busbar under each ANL fuse
  • Qty: 4 – 5/16″ x 2/0 Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Positive Wire to Starting Battery, Isolator x2, & House Battery Bank
  • Qty: 5 – 16 AWG Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Isolator Ign to Ignition Positive
  • Qty: 1 – Add-a-Fuse Kit
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Used to piggyback power for Ignition+ Wire
  • Qty: 5 – 16 AWG Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Isolator Gnd to Chassis Ground
  • Qty: 10 – 16 AWG Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Isolator Sig to Momentary Switch & from Momentary Switch to Chassis Ground
  • Qty: 1 – Momentary Switch
    • Placed in-line on Isolator Sig Wire
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

Misc Tools & Accessories (As Needed/Optional)
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

Wires, Lugs, Breakers, and Fuses

Wires
Add Wires Individually to Verify Quantities

Lugs
Add Lugs Individually to Verify Quantities

Fuses & Breakers
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

300W Solar | 300Ah Batteries

300Ah Lithium Battery Bank – 3x100W Solar – 2kW Inverter/Charger – Li-BIM Alternator Charging
EXPLORIST.life / Battle Born Solar Bundle [Affiliate Link] 100W Solar Panels [Affiliate Link] 50A ANL Fuse [Affiliate Link] Roof Entry Gland [Affiliate Link] 100A ANL Fuse [Affiliate Link] 250A ANL Fuse [Affiliate Link] 250A ANL Fuse [Affiliate Link] 15A Solar Disconnect [Affiliate Link] Master Battery Disconnect Switch [Affiliate Link] Exterior Shore Power Outlet [Affiliate Link] 250A Terminal Fuse [Affiliate Link] 300A Terminal Fuse [Affiliate Link] 30 A Shore Power Cord [Affiliate Link] 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 8 AWG x 5/16 Wire Lug 6 AWG x 5/16 Wire Lug 8 AWG x 5/16 Wire Lug 8 AWG x 5/16 Wire Lug 6 AWG x 5/16 Wire Lug 8 AWG x 5/16 Wire Lug Tutorial: How to Wire the Li-BIM Battery Isolator Tutorial: How to Wire the AC Side of Your Electrical System Tutorial: How to Wire for Shore Power Tutorial: How to Wire a Battery Bank Tutorial: How to Wire a Busbar Tutorial: How To Wire DC Distribution Block & Accessories Tutorial: How to wire a power distribution panel

EXPLORIST.life / Battle Born Solar Bundle [Affiliate Link]

Battery, Inverter, Charge Controller, Battery Monitor Discount Bundle Coming June 1.

100W Solar Panels [Affiliate Link]

50A ANL Fuse [Affiliate Link]

Roof Entry Gland [Affiliate Link]

100A ANL Fuse [Affiliate Link]

250A ANL Fuse [Affiliate Link]

250A ANL Fuse [Affiliate Link]

15A Solar Disconnect [Affiliate Link]

Master Battery Disconnect Switch [Affiliate Link]

Exterior Shore Power Outlet [Affiliate Link]

250A Terminal Fuse [Affiliate Link]

300A Terminal Fuse [Affiliate Link]

30 A Shore Power Cord [Affiliate Link]

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

2/0 x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

8 AWG x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

6 AWG x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

8 AWG x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

8 AWG x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

6 AWG x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

8 AWG x 5/16 Wire Lug

Total wire lug quantities for this wiring diagram are totaled at the bottom of the shopping list below.

Tutorial: How to Wire the Li-BIM Battery Isolator

Tutorial: How to Wire the AC Side of Your Electrical System

Tutorial: How to Wire for Shore Power

Tutorial: How to Wire a Battery Bank

Tutorial: How to Wire a Busbar

Tutorial: How To Wire DC Distribution Block & Accessories

Tutorial: How to wire a power distribution panel

CLICK HERE TO EXPAND THE SHOPPING LIST FOR DIGRAM ABOVE
SYSTEM STATS:
Solar Array: 300W (3x100W Panels)
Battery Bank: 300Ah (3x100Ah) Lithium – 12V
Inverter: 2000W Pure Sine Wave
Charging: Solar, Shore, Alternator
EXPLORIST.life Battery, Charge Controller, Inverter Bundle
Solar Charging System:
  • Qty: 3 – 100 Watt Solar Panel
    • Put these in the sun
  • Qty: 3 – Solar Panel Mounting Feet
    • Help mount solar panels to the roof
  • Qty: 1 – MC4 Connectors
    • Connecting Solar Panels to Wires going to Charge Controller
  • Qty: 40 – 10 AWG Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Solar Panel to Charge Controller
  • Qty: 40 – 10 AWG Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Solar Panel to Charge Controller
  • Qty: 1 – Roof Entry Gland
    • Waterproof Box for Running Wires through Roof
  • Qty: 1 – 1″ Wire Grommet
    • Mounted in roof under Roof Entry Gland
  • Qty: 1 – 15 Amp Solar Disconnect Switch
    • Mounted on Din Rail Between Solar Panels & Solar Contoller
  • Qty: 1 – Din Rail
    • To mount the Solar Disconnect Switch
  • Qty: 1 – Victron Smartsolar MPPT 150 | 35 – Bundle
    • Included in Bundle at Top of List
    • Solar Charge Controller
  • Qty: 5 – 8 AWG Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Charge Controller to Busbar
  • Qty: 5 – 8 AWG Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between Busbar & Charge Controller Equipment Ground
  • Qty: 5 – 8 AWG Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Charge Controller to Busbar
  • Qty: 2 – 5/16″ x 8 AWG Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Positive & Negative Wires from Charge Controller to Busbar
  • Qty: 2 – 5/16″ x 8 AWG Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Connecting Busbar to Charge Controller Equipment Ground
  • Qty: 1 – 50 Amp ANL Fuse
    • Check Wire, Lug, and Fuse List at Bottom of List
    • On Positive Busbar Protecting Red Wire to Charge Controller
  • Qty: 1 – ANL Fuse Holder
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Mounted to Busbar under each ANL fuse
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

Battery Bank, Busbar, & Inverter
  • Qty: 1 – 2000W Victron MultiPlus Compact Inverter Charger 12V – Bundle
    • Included in Bundle at Top of List
    • This Converts Your 12v DC Power to 120v AC Power
  • Qty: 1 – 300Ah Battle Born Lithium Battery Bundle
    • Included in Bundle at Top of List
    • These Store Your Power
  • Qty: 5 – 2/0 Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between Batteries & From Batteries to Busbar
  • Qty: 5 – 2/0 Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between Batteries & From Batteries to Busbar
  • Qty: 12 – 5/16″ x 2/0 Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Wires to Batteries & to Busbar
  • Qty: 1 – 300 Amp Terminal Fuse
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attached to Battery Protecting Red Wire to Busbar
  • Qty: 5 – 2/0 Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between Busbar & Inverter
  • Qty: 5 – 2/0 Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between Busbar & Inverter
  • Qty: 5 – 2/0 Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between Busbar & Inverter Equipment Ground
  • Qty: 5 – 2/0 Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between Busbar & Chassis Ground
  • Qty: 2 – 5/16″ x 2/0 Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Positive Wire from Busbar to Inverter
  • Qty: 2 – 5/16″ x 2/0 Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Negative Wire from Busbar to Inverter
  • Qty: 2 – 5/16″ x 2/0 Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Black Wire from Negative Busbar to Inverter Equipment Ground
  • Qty: 2 – 5/16″ x 2/0 Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Black Wire from Negative Busbar to Vehicle Chassis Ground
  • Qty: 1 – 250 Amp ANL Fuse
    • Check Wire, Lug, and Fuse List at Bottom of List
    • On Positive Busbar Protecting Red Wire to Inverter
  • Qty: 1 – ANL Fuse Holder
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Mounted to Busbar under each ANL fuse
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

DC Busbar
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

AC Circuits & Shore Power
  • Qty: 1 – 30 Amp Shore Power Cord
    • Connecting 30A Flanged Power Inlet to Shore Power
  • Qty: 1 – 30 Amp Shore Power Extension Cord
    • If your Shore Power Cord is too Short
  • Qty: 1 – 30A to 15A Adapter
    • For plugging your 30A shore power cord into a 15/20 amp standard outlet.
  • Qty: 1 – 30A Flanged Power Inlet
    • Connected to Outside of Camper
  • Qty: 10 – 10 AWG 3 Conductor Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From 30A Flanged Power Inlet to Inverter
  • Qty: 5 – 6 AWG 3 Conductor Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Inverter to Power Distribution Panel
  • Qty: 1 – Power Distribution Panel
    • For Distributing Power & Housing Breakers/Fuses
  • Qty: 1 – 50A AC Breaker
    • Check Wire, Lug, and Fuse List at Bottom of List
    • For AC Branch Circuits
  • Qty: 1 – 20A HOMT Tandem AC Breaker
    • Check Wire, Lug, and Fuse List at Bottom of List
    • For Standard 120V Outlet Circuits
  • Qty: 1 – 20A / 30A HOMT Tandem AC Breaker
    • Check Wire, Lug, and Fuse List at Bottom of List
    • For Circuits that include large loads (hot water heater)
  • Qty: 50 – 12 AWG 3 Conductor Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • For AC Branch Circuits
  • Qty: 6 – 120V GFCI Outlet
    • For plugging 120V Appliances into
  • Qty: 6 – Single Gang Electrical Box
    • For 120V GFCI Outlet
  • Qty: 6 – GFCI Wall Plates
    • For 120V GFCI Outlet
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

12v Distribution
  • Qty: 1 – Power Distribution Panel
    • For Distributing Power & Housing Breakers/Fuses
  • Qty: 1 – 100 AMP ANL Fuse
    • Check Wire, Lug, and Fuse List at Bottom of List
    • On Positive Busbar Protecting Red Wire to the Power Distribution Panel
  • Qty: 1 – ANL Fuse Holder
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Mounted to Busbar under each ANL fuse
  • Qty: 2 – 5/16″ x 6 AWG Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Positive & Negatives Wires to the Busbar from the Power Distribution Panel
  • Qty: 5 – 6 AWG Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Positive Wire From Busbar to Power Distribution Panel
  • Qty: 5 – 6 AWG Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Negative Wire From Busbar to Power Distribution Panel
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

Alternator Charging
  • Qty: – LI-BIM 225 Isolator
    • Connects and Disconnects House and Starting Battery Banks
  • Qty: 5 – 2/0 Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between LI-BIM 225 Isolator & Start Battery
  • Qty: 20 – 2/0 Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Between LI-BIM 225 Isolator & House Battery Bank
  • Qty: 1 – 250 Amp Terminal Fuse
    • Check Wire, Lug, and Fuse List at Bottom of List
    • On Starting Battery Protecting Red Wire to LI-BIM 225 Isolator
  • Qty: 1 – 250 Amp ANL Fuse
    • Check Wire, Lug, and Fuse List at Bottom of List
    • On Positive Busbar Protecting Red Wire to LI-BIM 225 Isolator
  • Qty: 1 – ANL Fuse Holder
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Mounted to Busbar under each ANL fuse
  • Qty: 4 – 5/16″ x 2/0 Lug
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Attaching Positive Wire to Starting Battery, Isolator x2, & House Battery Bank
  • Qty: 5 – 16 AWG Red Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Isolator Ign to Ignition Positive
  • Qty: 1 – Add-a-Fuse Kit
    • Check Wire, Lug, and Fuse List at Bottom of List
    • Used to piggyback power for Ignition+ Wire
  • Qty: 5 – 16 AWG Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Isolator Gnd to Chassis Ground
  • Qty: 10 – 16 AWG Black Wire
    • Check Wire, Lug, and Fuse List at Bottom of List
    • From Isolator Sig to Momentary Switch & from Momentary Switch to Chassis Ground
  • Qty: 1 – Momentary Switch
    • Placed in-line on Isolator Sig Wire
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

Misc Tools & Accessories (As Needed/Optional)
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

Wires, Lugs, Breakers, and Fuses

Wires
Add Wires Individually to Verify Quantities

Lugs
Add Lugs Individually to Verify Quantities

Fuses & Breakers
CLICK HERE TO ADD ALL AMAZON PRODUCTS TO AMAZON CART

300W Solar | 200Ah Batteries

200Ah Lithium Battery Bank – 3x100W Solar – 2kW Inverter/Charger – Li-BIM Alternator Charging
EXPLORIST.life / Battle Born Solar Bundle [Affiliate Link] 100W Solar Panels [Affiliate Link] 50A ANL Fuse [Affiliate Link] Roof Entry Gland [Affiliate Link] 100A ANL Fuse [Affiliate Link] 250A ANL Fuse [Affiliate Link] 250A ANL Fuse [Affiliate Link] 15A Solar Disconnect [Affiliate Link] Master Battery Disconnect Switch [Affiliate Link] Exterior Shore Power Outlet [Affiliate Link] 250A Terminal Fuse [Affiliate Link] 300A Terminal Fuse [Affiliate Link] 30 A Shore Power Cord [Affiliate Link] 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 2/0 x 5/16 Wire Lug 8 AWG x 5/16 Wire Lug 6 AWG x 5/16 Wire Lug 8 AWG x 5/16 Wire Lug 8 AWG x 5/16 Wire Lug 6 AWG x 5/16 Wire Lug 8 AWG x 5/16 Wire Lug Tutorial: How to Wire the Li-BIM Battery Isolator Tutorial: How to Wire the AC Side of Your Electrical System Tutorial: How to Wire for Shore Power Tutorial: How to Wire a Battery Bank Tutorial: How to Wire a Busbar Tutorial: How To Wire DC Distribution Block & Accessories Tutorial: How to wire a power distribution panel
